Adjustable Calibration Priority Valve. 3/4 "Gas Connections - Ref. 83596
Available for order
SHIPPED IN 2 / 3 DAYS
Order Online
- Delivery Italy: 1/2 days, from 9.90 €
- Delivery Europe: 2/3 days, from 17.90 €
N. of days may vary for locations that are difficult to reach
Price shown is inclusive of VAT
Price excl. VAT €246.51
VAT "IVA IT 22%" €54.23
Prior Valve. Tarat. Regol. 3/4 "
This valve adjust and mantain the flow into one port even over a wide range of pressure variation, and it bypass the excess fl ow to the second port.
The secondary port is compensated too.
Mounting:
Connect E to the pressure fl ow and P to the actuator or to a line of an hydraulic circuit where fl ow adjustment is needed.
Connect B to the tank or to a second actuator.
To adjust inlet pressure in P screw in or off hand wheel aftewr loosenng the locknut.
E - maximum input flow 120 l/min
P - maximum regulated flow 100 l/min
couplings 3/4" GAS
net weight 4.958 kg
