Gear Pump Group 2 Standard Conicity 1 - 8 Displacement 19 Cc Left Rotation - Hydr. Gr2 A42X Sx In Cast Iron - Ref. 81621
Available for order
SHIPPED IN 2 / 3 DAYS
Order Online
- Delivery Italy: 1/2 days, from 9.90 €
- Delivery Europe: 2/3 days, from 17.90 €
N. of days may vary for locations that are difficult to reach
Price shown is inclusive of VAT
Price excl. VAT €164.15
VAT "IVA IT 22%" €36.11
OEM code 8273977,5179714,84530154
Idr Pump. Gr2 A42X Left Cast Iron
Aluminum pump with cast iron cover and metric thread
Maximum pressure 250 Bar
plessey original references A42X
A 54 mm
B 103,5 mm
Thread suction M8
Center-distance suction 40 mm
Thread delivery M6
Center distance delivery 30
Fixing holes 7
Taper 1:8
Centering Ø 36,5 mm
Group 2
Swept volume 19 cc
Rotation Left
net weight 4 kg
link applicazioni
Fiat
1001151301380140158016018018804665555.665665806060.6665.6666668070.667667808080.668585.558558809095980
Below you will find one or two pages of the agricultural spare parts catalogue and all the products shown, which can be purchased.
Depending on the size or specification required, identify the product code (typically 5 numbers)
Below each image in the catalogue, you will find the article codes for purchasing.
Stock: the quantity shown (available), is for shipment within 3/4 working days.
To view additional information on a product, click on the code or thumbnail, then 'Show Details'.
Prices are per unit including 22% VAT.
If you do not find a product in the list, search for the 5-number code with the search engine above.
- Our technical department is available and will get back to you as soon as possible.
- In addition, send photographs via Whatsapp or Email indicating your need.
- Click on the shopping cart icon to add 'one unit'.
- The shipping cost is calculated at checkout.
