Pumps Gr. 2 (Standard Type) - 8,5 Cm3, Left Swept Volume 34 Cc Rotation Right

0/0

Gear Pump Group 2 Standard Displacement 34 Cc Right Rotation - Hydraulic Pump Gr2 Dx Cc. 34 - Ref. 82152

Name: Gear Pump Group 2 Standard Displacement 34 Cc Right Rotation - Hydraulic Pump Gr2 Dx Cc. 34 - Ref. 82152
Brand: MadeinItaly
SKU: CC-82152
Price: 414.21 EUR
Availability: InStock

Ref: CC-82152

Availability: 1

SHIPPED WITHIN 24 HOURS (MON–FRI)

Order Online

Only this item: Next working day dispatch
Delivery Italy: 1/2 days, from 9.90 €
Delivery Europe: 2/3 days, from 17.90 €

N. of days may vary for locations that are difficult to reach

Collection in shop, free of charge, at:

Vermezzo con Zelo (MI)

See Opening Hours and Address:

Monday to Friday: 08:30-12, 14-18
Saturday: 08:30-12
Sunday: Closed

Via Guglielmo Marconi, 2, 20071 Vermezzo con Zelo MI, Italia

€414.21 VAT inc.

€339.52 VAT exc.

Quantity

Description and Data sheet

Hydraulic Pump Gr2 Dx Cc. 34

Aluminum pump with cast iron cover and metric thread

Application on tractors: Fiat - Landini – Various

Continuous pressure 160 Bar

Maximum rotational speed 3000 rpm

Minimum rotational speed 700 rpm

A 102 mm

B 51 mm

Thread suction M8

Center-distance suction 40 mm

Thread delivery M6

Center distance delivery 30 mm

Intermittent pressure 170 Bar

Peak pressure 190 Bar

Taper 1:8

Centering Ø 36,5 mm

Group 2

Swept volume 34 cc

Rotation Right

net weight 4.1 kg

Data sheet

Displacement: 34 cc
Tapering: 1:08
Centring diameter: 36.5 mm
Distance from hole centre - B: 51 mm
Suction flange threading: M8
Outlet flange threading: M6
Fixing flange holes: 4x9.5 mm
Group: 2
Intake flange centre distance: 40 mm
Outlet flange centre distance: 30 mm
Length - A: 102 mm
Continuous pressure: 160 Bar
Intermittent pressure: 170 Bar
Peak pressure: 190 Bar
Rotation: Destra
Maximum rotation speed: 3000 rpm
Minimum rotation speed: 700 rpm
