Vane Flowmeter Flow Rate 5/100 L/Min - Ref. 27242
Available for order
SHIPPED IN 2 / 3 DAYS
Order Online
- Delivery Italy: 1/2 days, from 9.90 €
- Delivery Europe: 2/3 days, from 17.90 €
N. of days may vary for locations that are difficult to reach
Price shown is inclusive of VAT
Price excl. VAT € 314.71
VAT "IVA IT 22%" € 69.24
OEM code 4626315
Fluss. Wolf. 5 / 100L
Hi-precision and good price/performance ratio
T5 male/female fork connector for direct connection to control units
Operating status LED
Sapphire paddle pin to minimize rotational friction and maximize sensitivity and accurancy
Paddle assembly equipped with "TWIST" system for either cleaning or replacing operations without the need of any tools
Fully sealed and watertight electronic sensor
Tipical error: 1% of the full scale
Power supply 4 to 26 Vdc
Max. consumption 25 mA
0-12 Vdc pulse output with frequency proportional to rate
Parts in contact with the fluid are made of fiberglass and Delrin reinforced Nylon
flow rate 5/100 l/min
coupling T5
net weight 0.427 kg
