Ball Joint Ends
Front Spherical Support D.45 - Articulated Terminal - Ref. 50502
CC-50502
Available for order
SHIPPED IN 2 / 3 DAYS
Technical Data Sheet
- Height - i
- 77 mm
- Height - L1
- 48 mm
- Bevel height - L2
- 5 mm
- Total height - L
- 128 mm
- Hole diameter - D
- 45 mm
- Pin diameter - d4
- 6 mm
- Base diameter - d2
- 58 mm
- Outer diameter - d1
- 102 mm
- Thickness - S
- 32 mm
- Thickness - S1
- 27 mm
€51.42 VAT inc.
€42.15 VAT exc.
Data sheet
Height - i
- 77 mm
Height - L1
- 48 mm
Bevel height - L2
- 5 mm
Total height - L
- 128 mm
Hole diameter - D
- 45 mm
Pin diameter - d4
- 6 mm
Base diameter - d2
- 58 mm
Outer diameter - d1
- 102 mm
Thickness - S
- 32 mm
Thickness - S1
- 27 mm
