OREC ISSUED NO. HRC662B/OH-

Parts catalogue FLAIL MOWER

(EXPORT MODEL) HRC662B-OH

MODEL CODE

HRC662B/H 0301-○○○○○

	CONTENTS
Fig. 1	HANDLE -----------------------------	1
Fig. 2	FRAME ------------------------------	3
Fig. 3	TRANSMISSION ------------------	8
Fig. 4	ROTARY COVER -----------------	14
Fig. 5	ENGINE -----------------------------	19
Fig. 6	CRAWLER --------------------------	20
Fig. 7	LABEL -------------------------------	24
	OREC CO.,LTD Update : Jan 2015

1/25	HANDLE 1/2
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1415-223-00	Handle Bonnet	1
2	80-1417-253-00	Stopper	1
3	80-1417-255-00	Lever Grip (Red) 10	1
4	80-1417-918-10	Label, Cutting	1
5	80-1614-280-00	Switch Assy	1
6	80-1614-917-00	Label, Handle Up/Down	1
7	80-1614-918-00	Label, Handle Right/Left	1
8	83-1110-965-00	Handle Up/Down, Right/Left Wire	2
9	83-1415-453-10	Lever 27-05-0822S	2
10	83-1614-932-00	Tension Wire	1
11	89-1137-060122	Hexagonal Bolt (PW) M6*12	1
12	89-1158-060102	Cross recess Headed Screw (PWSW) M	4
13	89-2521-000050	E Type Ring 5	2
14	89-2521-000100	E Type Ring 10	1
15	0211-20400	Blade Tension Lever	1
16	0211-20500	Upper Cover	1
17	0211-70410	Stopper Return Spring	1

2/25	HANDLE 2/2
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1417-971-10	Blade Clutch Lever Return Spring	1
2	83-1530-463-00	Throttle Lever 27 (Steel)	1
3	83-1560-414-00	Handle Grip 27	2
4	83-1614-932-00	Tension Wire	1
5	83-1614-962-00	Side Clutch Wire	2
6	83-1761-457-00	Side Clutch Lever	2
7	89-1113-060602	Hexagonal Bolt (8T) M6*60	2
8	89-1551-060002	Hexagonal U Nut M6	2
9	89-2120-200152	Split Pin 2*15	1
10	89-2131-060002	Snap Pin 6	2
11	89-2521-000050	E Type Ring 5	1
12	0211-20100	Handle CMP	1
13	0211-20200	Driving Clutch Lever	1
14	0211-20300	Blade Clutch Lever	1
15	0211-20600	Brake Spring	1
16	0211-70500	Brake Wire	1
17	0211-70600	Label, Driving	1
18	0301-70500	Label, Throttle(GX270.340)	1
19	0301-71200	Throttle Wire (GX270.340)	1

3/25	FRAME 1/5
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1614-746-10	Side Cover	1
2	0282-20100	Clinometer Panel	1
3	0282-20200	Pointer for Clinometer	1
4	0282-72300	Clinometer Label	1
5	0304-62100	Belt Cover Outside CMP (GX270)	1
6	89-1137-060152	Hexagonal Bolt (PW) M6*15	3
7	89-1233-080162	Mini Hexagonal Bolt (PWSW) M8*16	5
8	89-1563-080003	Bag Hexagonal U Nut M8(UNI)	1
9	89-1711-080002	Flat Washer 8	1
10	Crawler Part	-	1	Page. 20 ～

4/25	FRAME 2/5
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1210-216-00	Stopper Pin	2
2	80-1210-217-00	Stopper Spring	2
3	80-1210-222-00	Handle Setting Collar	1
4	80-1310-203-00	Turntable for Handle	1
5	80-1310-215-00	Stopper Cap	2
6	80-1310-228-00	Handle Fix Nut	2
7	0302-10100	Handle Up/Down Stopper Arm CMP (GX	1
8	83-1210-133-00	Setting Bolt M12*160	1
9	89-1211-100202	Mini Hexagonal Bolt M10*20	2
10	89-1750-100002	Spring Washer 10	2
11	89-1750-120002	Spring Washer 12	2
12	89-2511-000850	Snap Ring (S85)	1
13	Handle Part	-	1	Page. 1 ～
14	Engine Part	-	1	Page. 19 ～

5/25	FRAME 3/5
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1560-551-00	Return Spring	2
2	80-1614-374-30	Brake Rod	1
3	80-1614-521-00	Transmission Pulley	1
4	80-1614-552-00	Tension Spring	2
5	0004-40600	Belt Holder	1
6	0211-54200	Driving Tension Arm	1
7	0256-40400	Knife Tension Arm	1
8	83-1032-765-00	Tension Pulley	2
9	89-1233-080162	Mini Hexagonal Bolt (PWSW) M8*16	1
10	89-1543-100002	Mini Hexagonal Nut (SW) M10	1
11	89-1711-100002	Flat Washer 10*18*1.6	1
12	89-2150-050200	Key 5*20 (round)	1
13	89-2511-000170	Snap Ring (S17)	2
14	89-2512-000400	Snap Ring (R40)	2
15	89-2521-000150	E Type Ring 15	2
16	89-3115-062034	Bearing 6203 2RS	2

6/25	FRAME 4/5
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	0253-16100	Change Lever CMP	1
2	0253-22410	Change Guide CMP	1
3	0253-22500	Change Rod Setting	1
4	0253-79100	Lever Grip 12.7	1
5	0256-20510	Rear Bracket	1
6	0301-10100	Under Bonnet CMP(GX270.340) HRC	1
7	0304-62200	Belt Cover Inside CMP (GX270.340)	1
8	89-1211-100162	Mini Hexagonal Bolt M10*16	2
9	89-1213-100202	Mini Hexagonal Bolt (8T) M10*20	4
10	89-1232-080162	Mini Hexagonal Bolt (SW) M8*16	6
11	89-1233-080162	Mini Hexagonal Bolt (PWSW) M8*16	5
12	89-1253-080162	Flange Mini Hexagonal Bolt (8T) M8*16	2
13	89-1750-080002	Spring Washer 8	2
14	89-1750-100002	Spring Washer 10	6
15	Rotary Cover Part	-	1	Page. 14 ～

7/25	FRAME 5/5
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	0251-11300	Change Plate	1
2	0251-11600	Change Lever Arm CMP	1
3	0301-20100	Main Frame (L) CMP	1
4	0301-20200	Main Frame (R) CMP	1
5	83-1565-329-00	Washer 13*22*2.3	1
6	89-1213-101302	Mini Hexagonal Bolt (8T) M10*130	1
7	89-1253-081453	Flange Mini Hexagonal Bolt (8T) M8*145	3
8	89-1543-080002	Mini Hexagonal Nut (SW) M8	3
9	89-1611-100042	Mini Hexagonal Nut M10	1
10	89-1711-060002	Flat Washer 6	2
11	89-1750-100002	Spring Washer 10	1
12	89-2131-120002	Snap Pin 12	1
13	89-2132-060002	Snap Pin 6 (with stopper)	2
14	Transmission Part	-	1	Page. 8 ～

8/25	TRANSMISSION 1/6
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1614-312-00	Brake Cover CMP	1
2	80-1614-314-00	Brake Cover	1
3	80-1920-153-00	Side Clutch Arm	2
4	80-1920-313-00	Brake Cover Spacer	1
5	0211-31800	Brake Packing (Large)	1
6	85-1711-315-00	Brake Drum	1
7	85-1711-317-00	Shoe Return Spring	2
8	85-1711-318-00	Brake Shoe Set	1
9	85-1445-317-00	Brake Packing (Small)	1
10	89-1111-060252	Hexagonal Bolt M6*25	3
11	89-1132-060122	Hexagonal Bolt (SW) M6*12	3
12	89-1543-080002	Mini Hexagonal Nut (SW) M8	2
13	89-1750-060002	Spring Washer 6	3
14	89-2511-000140	Snap Ring (S14)	1

9/25	TRANSMISSION 2/6
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1565-159-00	Shaft BB Reinforce Pipe	2
2	80-1920-197-00	Side Clutch Wire Receiver (L)	1
3	80-1920-198-00	Side Clutch Wire Receiver (R)	1
4	0251-04300	Change Arm CMP	1
5	0282-01100	Transmission Guard	1
6	0301-70200	Label, Transmission HRC662B	1
7	83-1020-349-00	Copper Packing 10.5*18*1.6	1
8	83-1484-255-00	Lock Nut ZUF M8	9
9	83-1493-255-00	Flange Lock Nut M10 (slender)	1
10	83-1565-111-00	Hexagonal Bolt (with Big Washer) M6*16	1
11	89-1252-100123	Flange Mini Hexagonal Bolt M10*12 (slender)	1
12	89-1253-081153	Flange Mini Hexagonal Bolt (8T) M8*115	2
13	89-1253-081203	Flange Mini Hexagonal Bolt (8T) M8*120	2
14	89-1253-081353	Flange Mini Hexagonal Bolt (8T) M8*135	2
15	89-1253-081403	Flange Mini Hexagonal Bolt (8T) M8*140	3
16	89-1254-101153	Flange Mini Hexagonal Bolt M10*115 P=1.25	1

10/25	TRANSMISSION 3/6
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1415-114-00	Side Clutch Fork	1
2	80-1425-112-00	Driving Clutch Folk Shaft	1
3	80-1575-152-10	Side Clutch Shaft BB Case	1
4	0297-08000	Oil Seal AP 35.55.16	1
5	0301-00210	Transmission Case (R )	1
6	0301-00400	Shaft BB Case (R )	1
7	83-1415-127-00	Seal Bolt (SW) M8*20	4
8	83-1415-671-00	Blind Cover 22	1
9	83-1415-672-00	Blind Cover 30	2
10	83-1517-685-00	Oil Cap 20	1
11	89-1232-080162	Mini Hexagonal Bolt (SW) M8*16	4
12	89-2111-030020	Spring Pin 3*20	1
13	89-2111-050020	Spring Pin 5*20	1
14	89-2512-000550	Snap Ring (R55)	1
15	89-3115-060064	Bearing 6006 2RS	2
16	89-5121-122207	Oil Seal UE 12.22.7	1
17	89-5121-153007	Oil Seal UE 15.30.7	1
18	89-5121-305007	Oil Seal UE 30.50.7	1

11/25	TRANSMISSION 4/6
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1575-140-00	Side Clutch Shaft	1
2	80-1575-129-10	2nd Shaft Gear 24T	1
3	80-1575-141-00	Side Clutch Gear 14T	2
4	80-1575-142-00	Side Clutch Gear 38T	1
5	80-1575-162-00	Side Clutch Spring	2
6	80-1920-130-00	Collar Ａ	1
7	80-1920-147-00	Axle Collar	1
8	0223-02500	Collar 6L	1
9	0251-01610	3nd Shaft Gear 22T	1
10	0282-00110	Axle CMP	1
11	0282-00500	2nd Shaft Gear 18T	1
12	0282-00600	3rd Shaft Gear 28T	1
13	83-1633-362-10	Thrust Washer 15*30*1.2	2
14	83-1830-368-00	Thrust Washer 18*26*1.0	4
15	89-2511-000150	Snap Ring (S15)	2
16	89-2511-000200	Snap Ring (S20)	2
17	89-3111-062024	Bearing 6202	4

12/25	TRANSMISSION 5/6
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1575-109-00	Swing Arm	1
2	0223-00400	Shift Fork Shaft	1
3	0223-00600	1st Shaft Gear 20T	1
4	0223-00700	1st Shaft Shift Gear 14T	1
5	0223-01200	Back Gear CMP	1
6	0223-01400	3rd Shaft	1
7	0223-02400	Collar 11L	1
8	0251-00300	Shift Folk	1
9	0251-01100	Trasmission 1st Shaft	1
10	0251-01300	2nd Shaft Gear 32T	1
11	0251-02100	3rd Shaft Gear 14T CMP	1
12	0282-00400	Spring	1
13	0301-00500	2nd Shaft	1
14	83-1310-371-00	Thrust Washer 20*30*1.0	2
15	83-1830-368-00	Thrust Washer 18*26*1.0	2
16	89-2120-200202	Split Pin 2*20	1
17	89-2511-000160	Snap Ring (S16)	1
18	89-3111-062024	Bearing 6202	4
19	89-3410-075000	Steel Ball 7.5	1
20	89-3510-012200	DU Bush 12.20	1
21	89-5221-009000	O Ring P9	1

13/25	TRANSMISSION 6/6
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1415-114-00	Side Clutch Fork	1
2	80-1425-112-00	Driving Clutch Folk Shaft	1
3	80-1575-152-10	Side Clutch Shaft BB Case	1
4	0282-00110	Axle CMP	1
5	0297-08000	Oil Seal AP 35.55.16	1
6	0301-00110	Transmission Case (L )	1
7	0301-00300	Shaft BB Case (L )	1
8	83-1415-127-00	Seal Bolt (SW) M8*20	4
9	83-1415-671-00	Blind Cover 22	1
10	83-1415-672-00	Blind Cover 30	2
11	83-1517-685-00	Oil Cap 20	1
12	89-1232-080162	Mini Hexagonal Bolt (SW) M8*16	4
13	89-1251-060102	Flange Hexagonal Bolt M6*10	1
14	89-2111-030020	Spring Pin 3*20	1
15	89-2111-050020	Spring Pin 5*20	1
16	89-2512-000550	Snap Ring (R55)	1
17	89-3115-060064	Bearing 6006 2RS	2
18	89-5121-122207	Oil Seal UE 12.22.7	1
19	89-5121-153007	Oil Seal UE 15.30.7	1
20	89-5121-305007	Oil Seal UE 30.50.7	1
21	89-5230-060000	Seal Washer 6	1

14/25	ROTARY COVER 1/5
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1613-733-10	Safety Cover	1
2	80-1614-906-00	Label, Safety Cover	1
3	0211-60500	Front Bumper	1
4	0223-76100	Label, Caution (Large)	1
5	0285-61200	Height Adjusting Bolt Receiver CMP	1
6	0285-62400	Height Adjusting Bolt CMP	1
7	0285-77000	Round Head Pin 10*80	1
8	83-1210-425-00	Lever Grip 10	1
9	84-1723-739-00	Cutting Height Adjusting Handle	1
10	89-1211-080252	Mini Hexagonal Bolt M8*25	2
11	89-1253-080202	Flange Mini Hexagonal Bolt (8T) M8*20	4
12	89-1543-080002	Mini Hexagonal Nut (SW) M8	4
13	89-1611-080042	Mini Hexagonal Nut M8	2
14	89-1711-100002	Flat Washer 10*18*1.6	2
15	89-1714-120002	Flat Washer 12	1
16	89-2111-050022	Spring Pin 5*22	1
17	89-2131-100002	Snap Pin 10	1
18	89-2181-100502	Flat Head Pin 10*50	1

15/25	ROTARY COVER 2/5
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1610-714-00	Front Arm Setting Shaft	2
2	80-1614-725-20	Front Wheel Fork	2
3	80-1614-726-00	Front Wheel Collar	2
4	80-1614-727-00	Front Wheel	2
5	0211-60400	Front Arm CMP	1
6	0256-60700	Dust Cover	2
7	83-1415-975-00	Grease Nipple M6	2
8	83-1610-192-00	Hexagonal Nut (slender) M12 P=1.25	2
9	83-1613-907-10	Label, Caution for Hand and Leg	2
10	83-1783-376-00	Thrust Washer 25*34*1.0	2
11	84-1783-791-00	Grease Nipple Bolt M14	2
12	89-1211-100952	Mini Hexagonal Bolt M10*95	2
13	89-1543-100002	Mini Hexagonal Nut (SW) M10	2
14	89-1714-120002	Flat Washer 12	2
15	89-1750-120002	Spring Washer 12	2
16	89-1750-140002	Spring Washer 14	2
17	89-3370-051105	Thrust Bearing 51105	2

16/25	ROTARY COVER 3/5
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1182-527-00	Tension Pulling Bolt	1
2	80-1488-928-10	Label, Caution for Belt Involving	1
3	80-1610-787-00	Flapper Holder	1
4	80-1614-315-00	Return Spring	1
5	80-1614-694-10	Knife Belt Cover	1
6	80-1614-764-00	Front Cover CMP	1
7	80-1614-781-10	Front Flapper	1
8	0211-63200	Front Tension Arm CMP	1
9	83-1032-765-00	Tension Pulley	1
10	83-1630-342-00	Washer 16*26*2.3	2
11	89-1137-060152	Hexagonal Bolt (PW) M6*15	5
12	89-1233-080162	Mini Hexagonal Bolt (PWSW) M8*16	2
13	89-1581-060042	Flange Cap Nut M6	5
14	89-1611-080042	Mini Hexagonal Nut M8	2
15	89-2511-000170	Snap Ring (S17)	1
16	89-2512-000400	Snap Ring (R40)	1
17	89-2521-000120	E Type Ring 12	2
18	89-2521-000150	E Type Ring 15	1
19	89-3115-062034	Bearing 6203 2RS	1
20	89-6123-003901	V Belt LBR-39	1

17/25	ROTARY COVER 4/5
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1610-787-00	Flapper Holder	1
2	80-1614-373-20	Knife Brake Spring	1
3	80-1614-621-30	Supporter Shaft	1
4	80-1614-634-20	Knife Pulley 155	1
5	80-1614-636-00	Supporter Pulley	2
6	80-1614-691-30	Supporter Pipe CMP	1
7	80-1614-782-10	Rear Flapper	1
8	0212-72100	Hexagonal Bolt(8T) M10*25(Meck)	2
9	0231-37100	Knife Brake	1
10	83-1565-315-00	Washer 8*36*4.5	2
11	83-1610-125-00	Hexagonal Bolt (8T) M10*35	1
12	83-1610-322-00	Washer 10*36*6	1
13	89-1137-060152	Hexagonal Bolt (PW) M6*15	5
14	89-1213-080182	Mini Hexagonal Bolt (8T) M8*18	4
15	89-1581-060042	Flange Cap Nut M6	5
16	89-1750-080002	Spring Washer 8	4
17	89-1750-100002	Spring Washer 10	3
18	89-2151-050350	Key 5*35 (half round)	2
19	89-2151-070300	Key 7*30 (half round)	1
20	89-2521-000150	E Type Ring 15	1
21	89-3115-060044	Bearing 6004 2RS	2

18/25	ROTARY COVER 5/5
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1610-804-00	BB Case	2
2	80-1610-821-00	Hammer Knife Blade	38
3	80-1612-813-00	Dust Cover	2
4	80-1614-703-30	Rotary Cover CMP	1
5	80-1614-705-00	Flat Head Bolt M8*18	6
6	80-1614-800-00	Knife Drum ASSY	1
7	80-1614-810-00	BB Case Cover	1
8	0285-60400	Knife Shaft BB Case Holder	1
9	83-1610-124-00	Hexagonal Bolt (8T) M10*25 (left screw)	1
10	83-1610-321-00	Washer 10*36*4.5	1
11	83-1610-835-00	Knife Setting Bolt Set	19
12	83-1613-907-10	Label, Caution for Hand and Leg	2
13	89-1253-080162	Flange Mini Hexagonal Bolt (8T) M8*16	8
14	89-1671-080042	Mini Cap Nut M8	6
15	89-1750-080002	Spring Washer 8	14
16	89-1812-100002	Toothed washer (inside) 10	1
17	89-2512-000620	Snap Ring (R62)	2
18	89-3115-062064	Bearing 6206 2RS	2
19	0285-60100	Knife Shaft BB Case Set	1

19/25	ENGINE 1/1
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1614-514-20	Engine Pulley 132	1
2	80-1614-561-20	Belt Holder	1
3	0211-30300	Engine Fitting Plate with Bolt (M)	2
4	0211-31100	Whirl Stop Plate A10 (H14)	4
5	0304-61400	Recoil Cover CMP (GX270)	1
6	0304-61800	Recoil Cover Setting Bolt (GX270.340)	3
7	0304-62500	Muffler Guard CMP (GX270)	1
8	83-1565-315-00	Washer 8*36*4.5	1
9	89-1111-060352	Hexagonal Bolt M6*35	1
10	89-1211-100402	Mini Hexagonal Bolt M10*40	4
11	89-1233-080162	Mini Hexagonal Bolt (PWSW) M8*16	2
12	89-1251-050163	Flange Hexagonal Bolt M5*16	2
13	89-1251-060102	Flange Hexagonal Bolt M6*10	3
14	89-1253-080202	Flange Mini Hexagonal Bolt (8T) M8*20	1
15	89-1543-100002	Mini Hexagonal Nut (SW) M10	8
16	89-1713-100002	Flat Washer 10 (large)	6
17	89-1750-100002	Spring Washer 10	1
18	89-2151-070400	Key 7*40 (harf round)	1
19	9009-0271	GX270UT2 SAX4	1
20	89-6123-006301	V Belt SBR-63	1
21	89-6122-004701	V Belt SAR-47	1

20/25	CRAWLER 1/4
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	0282-30100	Driving Sprocket CMP	1
2	0282-31310	Axle Pin 10*50	1
3	0282-70200	Rubber Crawler 160W*60P*24L	1
4	0282-70300	Dust Seal	1
5	0301-30700	Stone Guard (L) CMP	1
6	89-1233-080202	Mini Hexagonal Bolt (PWSW) M8*20	2
7	89-2132-100002	Snap Pin 10 (with stopper)	1

21/25	CRAWLER 2/4
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	0282-30200	Crawler Arm (L) CMP	1
2	0282-30400	Induction Ring Attachment CMP	1
3	0282-30500	Turn Wheel CMP	1
4	0282-70400	Blind Cover 35	1
5	83-1415-975-00	Grease Nipple M6	1
6	89-1111-141407	Hexagonal Bolt M14*140	1
7	89-1232-080162	Mini Hexagonal Bolt (SW) M8*16	1
8	89-1511-140042	Hexagonal Nut M14	1
9	89-1713-080002	Flat Washer 8 (large)	1
10	89-2511-000630	Snap Ring (S63)	1
11	89-3115-060034	Bearing 6003 2RS	1
12	89-3115-060044	Bearing 6004 2RS	1
13	89-5121-254210	Oil Seal UE 25.42.10	1
14	89-5222-065000	O Ring G65	1

22/25	CRAWLER 3/4
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	0282-30800	Spacer for Connecting Bar	2
2	0282-31100	Connecting Bar (Rear)	1
3	0282-31200	Connecting Bar (Front)	1
4	0282-70200	Rubber Crawler 160W*60P*24L	1
5	0282-71100	Tension Spring for Crawler	1
6	0301-30600	Stone Guard (R) CMP	1
7	89-1213-100352	Mini Hexagonal Bolt (8T) M10*35	2
8	89-1233-080202	Mini Hexagonal Bolt (PWSW) M8*20	2
9	89-1236-100252	Mini Hexagonal Bolt (PWSW) M10*25	2
10	89-1714-100002	Flat Washer 10	2
11	89-1750-100002	Spring Washer 10	2

23/25	CRAWLER 4/4
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	0282-30100	Driving Sprocket CMP	1
2	0282-30300	Crawler Arm (R) CMP	1
3	0282-30400	Induction Ring Attachment CMP	1
4	0282-30500	Turn Wheel CMP	1
5	0282-31310	Axle Pin 10*50	1
6	0282-70300	Dust Seal	1
7	0282-70400	Blind Cover 35	1
8	83-1415-975-00	Grease Nipple M6	1
9	89-1111-141407	Hexagonal Bolt M14*140	1
10	89-1232-080162	Mini Hexagonal Bolt (SW) M8*16	1
11	89-1511-140042	Hexagonal Nut M14	1
12	89-1713-080002	Flat Washer 8 (large)	1
13	89-2132-100002	Snap Pin 10 (with stopper)	1
14	89-2511-000630	Snap Ring (S63)	1
15	89-3115-060034	Bearing 6003 2RS	1
16	89-3115-060044	Bearing 6004 2RS	1
17	89-5121-254210	Oil Seal UE 25.42.10	1
18	89-5222-065000	O Ring G65	1

24/25

LABEL 1/2

⑭

⑳ / ④

23

⑥

② ①

22

serial

21 numbe

23

⑧

⑬ ⑫

⑤ ➃

⑮

⑩

⑦ ⑯

⑨

⑱

③ ⑲ ➃

25/25	LABEL 2/2
Ref.	Parts Number	Parts Name	Quantity	Remarks
1	80-1010-933-00	Label, CE	1
2	80-1020-932-00	Label, Noise 100db	1
3	80-1417-918-10	Label, Cutting	1
4	80-1484-928-00	Label,Oil Quantity 1.6L	1
5	80-1488-928-10	Label, Caution for Belt Involving	2
6	80-1614-904-00	Label, Bonnet	1
7	80-1614-905-00	Label, Belt Case	1
8	80-1614-906-00	Label, Safety Cover	1
9	80-1614-917-00	Label, Handle Up/Down	1
10	80-1614-918-00	Label, Handle Right/Left	1
11	0211-70600	Label, Driving	1
12	0215-83200	Label, Protection Equipment	1
13	0223-72910	Attention Mark for Slope	1
14	0223-76100	Label, Caution (Large)	1
15	0251-70400	Label, Change	1
16	0282-72300	Clinometer Label	1
17	0301-70100	Label, Model HRC662B	1
18	0301-70200	Label, Transmission HRC662B	1
19	0301-70500	Label, Throttle(GX270.340)	1
20	0304-71500	Label for Left Screw	1
21	83-1050-901-00	Label, OREC	1
22	83-1310-902-00	OREC Mark	1
23	83-1613-907-10	Label, Caution for Hand and Leg	4
