GR703A PART CATALOG
NO. GR703A-01
GR703A PART CATALOG
NO. GR703A-01
Frame Handle Front arm
Cutting Parts & Cover Transmission
1 - 10
11 - 15
16
17 - 21
22 - 30
|
Frame 1/10 1/30 |
||||
|
10 |
0223-72910 |
Attention Mark for
Slope |
1 |
|
|
9 |
0223-60200 |
Side Cover CMP |
1 |
|
|
8 |
0223-60100 |
Front Cover CMP |
1 |
|
|
7 |
0215-83200 |
Label, Protection Equipment |
1 |
|
|
6 |
0208-73500 |
Wire Band (KV-200 Brack) |
2 |
|
|
5 |
0208-73400 |
Wire Band (KV-150 Brack) |
1 |
|
|
4 |
89-1233-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
7 |
|
|
3 |
83-1030-904-10 |
GTEC Mark |
1 |
|
|
2 |
80-1488-928-10 |
Label, Caution for Belt Involving |
1 |
|
|
1 |
80-1482-468-00 |
Rubber L285 |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Frame 2/10 2/30
|
||||
|
16 |
0223-76300 |
Label, Main GR703A |
1 |
|
|
15 |
0223-76100 |
Label, Caution (large) |
1 |
|
|
14 |
0223-72100 |
Rubber L55 |
1 |
|
|
13 |
0223-71900 |
Label, Change |
1 |
|
|
12 |
0223-71500 |
Rubber L92 |
1 |
|
|
11 |
0223-61300 |
Under Cover (L) CMP |
1 |
|
|
10 |
0223-61200 |
Under Cover (R) |
1 |
|
|
9 |
0223-60300 |
Transmission Cover |
1 |
|
|
8 |
0223-10700 |
Change Lever CMP |
1 |
|
|
7 |
89-3510-012150 |
DU Bush 12.15 |
2 |
|
|
6 |
89-2521-000100 |
E Type Ring 10 |
1 |
|
|
5 |
89-1233-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
5 |
|
|
4 |
83-1711-426-00 |
Lever Grip 12 |
1 |
|
|
3 |
80-1035-982-10 |
Rubber L135 |
1 |
|
|
2 |
80-1020-932-00 |
Label, Noise 100db |
1 |
|
|
1 |
80-1010-933-00 |
Label, CE |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Frame 3/10 3/3 |
||||
|
10 |
- |
Handle Assy |
1 |
|
|
9 |
0223-74100 |
Handle Fixing Bolt M12*40(Slender) |
1 |
|
|
8 |
0223-23300 |
Foot Guard Flapper Support |
1 |
|
|
7 |
0223-23200 |
Foot Guard Flapper |
1 |
|
|
6 |
0223-23100 |
Foot Guard CMP |
1 |
|
|
5 |
89-1750-120002 |
Spring Washer 12 |
1 |
|
|
4 |
89-1233-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
2 |
|
|
3 |
89-1137-060152 |
Hexagonal Bolt (PW) M6*15 |
5 |
|
|
2 |
83-1575-189-00 |
Flange Cap Nut M6 |
5 |
|
|
1 |
0013-10300 |
Handle Fixing Washer |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Frame 4/10 4/30
|
||||
|
18 |
- |
Front Arm Assy |
1 |
|
|
17 |
0223-30500 |
Wheel Boss |
2 |
|
|
16 |
0215-81500 |
Label, Grease |
2 |
|
|
15 |
89-2151-070400 |
Key 7*40(harf round) |
2 |
|
|
14 |
89-1750-100002 |
Spring Washer 10 |
2 |
|
|
13 |
89-1750-080002 |
Spring Washer 8 |
18 |
|
|
12 |
89-1631-080043 |
Flange Mini Hexagonal Nut M8 |
2 |
|
|
11 |
89-1611-080042 |
Mini Hexagonal Nut M8 |
12 |
|
|
10 |
89-1211-080202 |
Mini Hexagonal Bolt M8*20 |
12 |
|
|
9 |
89-1211-080162 |
Mini Hexagonal Bolt M8*16 |
12 |
|
|
8 |
89-1113-100302 |
Hexagonal Bolt (8T) M10*30 |
2 |
|
|
7 |
83-1610-321-00 |
Washer 10*36*4.5 |
2 |
|
|
6 |
80-1210-412-00 |
Tire Assy (Right) 350-6 |
2 |
|
|
5 |
80-1210-411-00 |
Tire Assy (Left) 350-6 |
2 |
|
|
4 |
80-1210-407-00 |
Wheel Assy 3.50-6 |
4 |
|
|
3 |
80-1210-404-00 |
Tube 3.50-6 |
4 |
|
|
2 |
80-1210-401-00 |
Tire 3.50-6 |
4 |
|
|
1 |
80-1021-227-00 |
Handle Fixing Bolt M8*45 |
2 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Frame 5/10 5/30 |
||||
|
17 |
0223-70800 |
Tension Return Spring |
1 |
|
|
16 |
0223-70200 |
Driving Clutch Wire |
1 |
|
|
15 |
0223-42200 |
Belt Holder (B) |
1 |
|
|
14 |
0223-41110 |
Belt Holder Collar |
2 |
|
|
13 |
0223-40800 |
Tension arm (Driving) |
1 |
|
|
12 |
0223-40600 |
Belt Holder,Transmission |
1 |
|
|
11 |
89-6122-003800 |
V Belt LA-38 |
1 |
|
|
10 |
89-3510-016150 |
DU Bush 16.15 |
2 |
|
|
9 |
89-3115-062034 |
Bearing 6203 2RS |
1 |
|
|
8 |
89-2521-000120 |
E Type Ring 12 |
1 |
|
|
7 |
89-2512-000400 |
Snap Ring
（R40） |
1 |
|
|
6 |
89-2511-000170 |
Snap Ring （S17） |
1 |
|
|
5 |
89-2132-060002 |
Snap Pin 6 |
1 |
|
|
4 |
89-1711-060002 |
Flat Washer 6 |
1 |
|
|
3 |
89-1233-080252 |
Mini Hexagonal Bolt (PWSW) M8*25 |
2 |
|
|
2 |
89-1233-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
2 |
|
|
1 |
83-1032-765-00 |
Tension Pulley |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Frame 6/10 6/30 |
||||
|
15 |
0223-70500 |
Blade brake wire |
1 |
|
|
14 |
0223-70400 |
Cutting Clutch Wire |
1 |
|
|
13 |
0223-40900 |
Tension arm (Knife) |
1 |
|
|
12 |
0223-40700 |
Belt Support, Knife |
1 |
|
|
11 |
89-6123-005003 |
V Belt LB-50（ＳＧ1000） |
1 |
|
|
10 |
89-3510-016150 |
DU Bush 16.15 |
2 |
|
|
9 |
89-3115-062034 |
Bearing 6203 2RS |
1 |
|
|
8 |
89-2521-000120 |
E Type Ring 12 |
1 |
|
|
7 |
89-2512-000400 |
Snap Ring （R40） |
1 |
|
|
6 |
89-2511-000170 |
Snap Ring （S17） |
1 |
|
|
5 |
89-2120-200152 |
Split Pin 2*15 |
1 |
|
|
4 |
89-1711-060002 |
Flat Washer 6 |
1 |
|
|
3 |
89-1233-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
1 |
|
|
2 |
83-1032-765-00 |
Tension Pulley |
1 |
|
|
1 |
80-1030-558-00 |
Kinfe Tension Return Spring |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Frame 7/10 7/30
|
||||
|
19 |
0231-74300 |
Cutting Height Adjustment Collar |
1 |
|
|
18 |
0223-71800 |
Label, Cutting Height Adjustment |
1 |
|
|
17 |
0223-52100 |
Cutting Height Adjustment Screw |
1 |
|
|
16 |
0223-50900 |
Connecting Plate |
2 |
|
|
15 |
0223-50600 |
Cutting Height Adjustment Shaft |
1 |
|
|
14 |
0223-50500 |
Cutting Height Adjusting Bolt Receiver Pipe |
1 |
|
|
13 |
0223-50400 |
Cutting Up/Down Adjusting Shaft CMP |
1 |
|
|
12 |
89-2521-000120 |
E Type Ring 12 |
1 |
|
|
11 |
89-2181-100502 |
Flat Head Pin 10*50 |
1 |
|
|
10 |
89-2131-100002 |
Snap Pin 10 |
1 |
|
|
9 |
89-2111-050022 |
Spring Pin 5*22 |
1 |
|
|
8 |
89-1750-080002 |
Spring Washer 8 |
4 |
|
|
7 |
89-1711-120002 |
Flat Washer 12 |
1 |
|
|
6 |
89-1711-100002 |
Flat Washer 10 |
2 |
|
|
5 |
89-1233-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
4 |
|
|
4 |
83-1713-166-00 |
Pin Round-Head 10*80 |
1 |
|
|
3 |
83-1210-425-00 |
Lever Grip 10 |
1 |
|
|
2 |
84-1723-739-00 |
Cutting Height Adjusting Handle |
1 |
|
|
1 |
80-1488-747-00 |
Bolt for Right Cover Up/Down Arm |
4 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Frame 8/10 8/30
|
||||
|
14 |
- |
Cutting Cover Assy |
1 |
|
|
13 |
0223-61100 |
Knife Pulley Guard (B) |
1 |
|
|
12 |
0223-60900 |
Setting Bolt |
2 |
|
|
11 |
0223-60800 |
Knife Pulley Guard (A) |
2 |
|
|
10 |
0223-50800 |
Link Bolt |
4 |
|
|
9 |
0223-50700 |
Link Arm CMP |
4 |
|
|
8 |
89-2521-000100 |
E Type Ring 10 |
4 |
|
|
7 |
89-1750-100002 |
Spring Washer 10 |
4 |
|
|
6 |
89-1750-080002 |
Spring Washer 8 |
2 |
|
|
5 |
89-1714-100002 |
Flat Washer 10 |
4 |
|
|
4 |
89-1611-080042 |
Mini Hexagonal Nut M8 |
2 |
|
|
3 |
89-1561-100002 |
Mini Hexagonal U Nut M10 |
4 |
|
|
2 |
89-1561-080002 |
Mini Hexagonal U Nut M8 |
2 |
|
|
1 |
89-1213-080202 |
Mini Hexagonal Bolt (8T) M8*20 |
2 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Frame 9/10 9/30
|
||||
|
24 |
9003-0010 |
KAWASAKI ENGINE FE290D |
1 |
|
|
23 |
0223-76200 |
Label, Caution for
Engine etc |
1 |
|
|
22 |
0223-70700 |
Wire, Side Clutch |
2 |
|
|
21 |
0223-60700 |
Muffler Guard CMP |
1 |
|
|
20 |
0223-42100 |
Engine Pulley(GR703A) |
1 |
|
|
19 |
0223-20110 |
Frame CMP |
1 |
|
|
18 |
0215-81900 |
Label, Oiling |
4 |
|
|
17 |
89-2151-070350 |
Key 7*35(harf round) |
1 |
|
|
16 |
89-2132-060002 |
Snap Pin 6 |
2 |
|
|
15 |
89-1750-080002 |
Spring Washer 8 |
5 |
|
|
14 |
89-1750-060002 |
Spring Washer 6 |
1 |
|
|
13 |
89-1750-050003 |
Spring Washer 5 |
2 |
|
|
12 |
89-1713-060002 |
Flat Washer(Large) 6 |
1 |
|
|
11 |
89-1711-060002 |
Flat Washer 6 |
2 |
|
|
10 |
89-1543-080002 |
Mini Hexagonal Nut (SW) M8 |
4 |
|
|
9 |
89-1254-101253 |
Flange Hexagonal Bolt M10*1.25*125 |
1 |
|
|
8 |
89-1253-080352 |
Mini Flange Bolt(8T) M8*35 |
4 |
|
|
7 |
89-1253-080302 |
Mini Flange Bolt(8T) M8*30 |
1 |
|
|
6 |
89-1253-080162 |
Mini Flange Bolt(8T) M8*16 |
4 |
|
|
5 |
89-1251-050123 |
Flange Hexagonal Bolt M5*12 |
2 |
|
|
4 |
89-1113-060162 |
Hexagonal Bolt (8T) M6*16 |
1 |
|
|
3 |
83-1565-315-00 |
Washer 8*36*4.5 |
1 |
|
|
2 |
83-1493-2550-00 |
Washer Based Rock Nut(slender)M10 |
1 |
|
|
1 |
80-1751-516-00 |
Collar 15L (M) |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Frame 10/10 |
|
|
10/30 |
|
|
22 |
0223-72200 |
Brake Pulling Spring |
1 |
|
|
21 |
0223-70300 |
Brake wire |
1 |
|
|
20 |
0223-40200 |
Transmission Pulley |
1 |
|
|
19 |
0223-20300 |
Brake Bracket CMP |
1 |
|
|
18 |
0223-01000 |
Transmission Case ASSY |
1 |
|
|
17 |
89-2511-000140 |
Snap Ring （S14） |
1 |
|
|
16 |
89-2181-060142 |
Flat Head Pin 6*14 |
1 |
|
|
15 |
89-2150-050250 |
Key 5*25(round) |
1 |
|
|
14 |
89-1750-100002 |
Spring Washer 10 |
1 |
|
|
13 |
89-1711-060002 |
Flat Washer 6 |
1 |
|
|
12 |
89-1611-100042 |
Mini Hexagonal Nut M10 |
1 |
|
|
11 |
89-1138-060162 |
Hexagonal Bolt (SW) M6*16 |
3 |
|
|
10 |
89-1138-060122 |
Hexagonal Bolt (SW) M6*12 |
3 |
|
|
9 |
85-1445-318-00 |
Brake Packing(large) |
1 |
|
|
8 |
85-1445-317-00 |
Brake Packing(small) |
1 |
|
|
7 |
83-1712-923-00 |
Label, Oil Quantity 1.6 |
1 |
|
|
6 |
83-1035-323-00 |
Washer 10*30*3.2 |
1 |
|
|
5 |
85-1711-317-00 |
Shoe Return Spring |
2 |
|
|
4 |
85-1711-316-00 |
Brake Shoe |
1 |
|
|
3 |
85-1711-315-00 |
Brake Drum |
1 |
|
|
2 |
80-1614-314-00 |
Brake Cover |
1 |
|
|
1 |
80-1614-312-00 |
Brake Cover CMP |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Handle 1/5 |
|
|
11/30 |
|
|
5 |
0223-70600 |
Throttle Wire |
1 |
|
|
4 |
0223-60500 |
Handle Bonnet CMP |
1 |
|
|
3 |
89-1159-060168 |
Truss Mini Screw M6*16 |
6 |
|
|
2 |
80-1791-953-00 |
Throttle lever |
1 |
|
|
1 |
80-1020-902-00 |
Label (Large) |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Handle 2/5 |
|
|
12/30 |
|
|
9 |
0223-70700 |
Wire, Side Clutch |
2 |
|
|
8 |
0223-70500 |
Wire,Blade brake |
1 |
|
|
7 |
0223-70400 |
Wire, Cutting Clutch |
1 |
|
|
6 |
0223-70300 |
Wire, Brake |
1 |
|
|
5 |
0223-70200 |
Driving Clutch Wire |
1 |
|
|
4 |
89-2120-200152 |
Split Pin 2*15 |
2 |
|
|
3 |
89-1711-060002 |
Flat Washer 6 |
2 |
|
|
2 |
80-1515-966-00 |
Clutch Spring |
1 |
|
|
1 |
80-1425-551-00 |
Differential Lock Spring |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Handle 3/5
|
|
|
13/30 |
|
|
7 |
0223-71100 |
Blade Clutch Return Spring |
1 |
|
|
6 |
0223-10600 |
Blade Clutch Rod |
1 |
|
|
5 |
0223-10500 |
Blade Clutch Stopper |
1 |
|
|
4 |
89-2521-000100 |
E Type Ring 10 |
1 |
|
|
3 |
89-2181-060142 |
Flat Head Pin 6*14 |
1 |
|
|
2 |
89-2132-060002 |
Snap Pin 6 |
1 |
|
|
1 |
89-1711-060002 |
Flat Washer 6 |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Handle 4/5
|
|
|
14/30 |
|
|
8 |
0223-10800 |
Wire pulling CMP |
1 |
|
|
7 |
0211-70400 |
Stopper return spring |
1 |
|
|
6 |
0211-20400 |
Blade tension lever |
1 |
|
|
5 |
89-2521-000100 |
E Type Ring 10 |
1 |
|
|
4 |
89-2521-000050 |
E Type Ring 5 |
2 |
|
|
3 |
89-1711-060002 |
Flat Washer 6 |
2 |
|
|
2 |
80-1417-255-00 |
Lever Grip(Red) 10 |
1 |
|
|
1 |
80-1417-253-00 |
Stopper |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Handle 5/5 |
|
|
15/30 |
|
|
10 |
0223-71700 |
Label, Driving Clutch |
1 |
|
|
9 |
0223-10300 |
Drive Clutch Lever |
1 |
|
|
8 |
0223-10200 |
Knife Clutch Lever |
1 |
|
|
7 |
0223-10100 |
Handle CMP |
1 |
|
|
6 |
89-2131-080002 |
Snap Pin 8 |
2 |
|
|
5 |
89-1551-060002 |
Hexagonal U Nut M6 |
2 |
|
|
4 |
89-1113-060552 |
Hexagonal Bolt (8T) M6*55 |
2 |
|
|
3 |
83-1761-457-00 |
Side Clutch Lever |
2 |
|
|
2 |
83-1560-414-00 |
Handle Grip 27 |
2 |
|
|
1 |
80-1417-918-00 |
Label, Cutting |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Front arm 1/1 |
|
|
16/30 |
|
|
14 |
0223-70100 |
Front Wheel (G-250N) |
2 |
|
|
13 |
0223-30300 |
Front Wheel Fork |
2 |
|
|
12 |
0223-24100 |
Front Arm CMP |
1 |
|
|
11 |
89-3511-020200 |
DU Bush 20.20.31F |
4 |
|
|
10 |
89-2511-000200 |
Snap Ring （S20） |
2 |
|
|
9 |
89-1750-100002 |
Spring Washer 10 |
2 |
|
|
8 |
89-1611-100042 |
Mini Hexagonal Nut M10 |
2 |
|
|
7 |
89-1561-100002 |
Mini Hexagonal U Nut M10 |
2 |
|
|
6 |
89-1213-100202 |
Mini Hexagonal Bolt (8T) M10*20 |
2 |
|
|
5 |
89-1211-100952 |
Mini Hexagonal Bolt M10*95 |
2 |
|
|
4 |
83-1490-337-00 |
Washer 20*38*3.2 |
2 |
|
|
3 |
83-1415-975-00 |
Grease Nipple M6 |
2 |
|
|
2 |
83-1310-371-00 |
Thrust Washer 20*30*1.0 |
2 |
|
|
1 |
80-1614-726-00 |
Front Wheel Collar |
2 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Cutting Parts
& Cover 1/5 17/30
|
||||
|
15 |
0223-72500 |
Spring |
1 |
|
|
14 |
0223-51400 |
Knife Brake |
1 |
|
|
13 |
0223-51300 |
Knife Brake Bracket CMP |
1 |
|
|
12 |
0223-40300 |
Knife Pulley |
1 |
|
|
11 |
0215-81900 |
Label, Oiling |
4 |
|
|
10 |
89-3510-012200 |
DU Bush 12.20 |
2 |
|
|
9 |
89-2521-000100 |
E Type Ring 10 |
1 |
|
|
8 |
89-2151-070300 |
Key 7*30(harf round) |
1 |
|
|
7 |
89-1750-080002 |
Spring Washer 8 |
1 |
|
|
6 |
89-1253-080252 |
Flange Hexagonal Bolt (8T) M8*25 |
1 |
|
|
5 |
89-1233-080202 |
Mini Hexagonal Bolt (PWSW) M8*20 |
2 |
|
|
4 |
83-1754-329-00 |
Washer 13*22*1.0 |
1 |
|
|
3 |
83-1210-913-00 |
Label (0.4) |
1 |
|
|
2 |
83-1020-312-00 |
Washer 8*30*3.2 |
1 |
|
|
1 |
80-1488-926-10 |
Label, Caution for
Knife |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Cutting Parts
& Cover 2/5 18/30
|
||||
|
20 |
0223-71400 |
Push Nut 10 |
1 |
|
|
19 |
0223-56400 |
Front Cover CMP |
1 |
|
|
18 |
0223-56300 |
Cover CMP (Right) |
1 |
|
|
17 |
0223-56200 |
Front Guard CMP |
1 |
|
|
16 |
0221-52400 |
Right Cover Up/Down Arm |
1 |
|
|
15 |
89-1750-120002 |
Spring Washer 12 |
2 |
|
|
14 |
89-1750-080002 |
Spring Washer 8 |
6 |
|
|
13 |
89-1714-100002 |
Flat Washer 10 |
1 |
|
|
12 |
89-1711-080002 |
Flat Washer 8 |
5 |
|
|
11 |
89-1671-120042 |
Mini Hexagonal Cap Nut M12 |
2 |
|
|
10 |
89-1671-080042 |
Mini Hexagonal Cap Nut M8 |
5 |
|
|
9 |
89-1611-080042 |
Mini Hexagonal Nut M8 |
1 |
|
|
8 |
89-1233-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
2 |
|
|
7 |
89-1211-080202 |
Mini Hexagonal Bolt M8*20 |
1 |
|
|
6 |
89-1211-080182 |
Mini Hexagonal Bolt
M8*18 |
5 |
|
|
5 |
83-1260-9080-00 |
Attention Mark for
Reversing |
1 |
|
|
4 |
80-1493-748-00 |
Right Cover Receiver Bolt |
2 |
|
|
3 |
80-1488-926-10 |
Label, Caution for
Knife |
2 |
|
|
2 |
80-1488-749-00 |
Spring for Right Cover |
1 |
|
|
1 |
80-1488-747-00 |
Bolt for Right Cover Up/Down Arm |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Cutting Parts
& Cover 3/5 19/30
|
||||
|
16 |
0223-71300 |
Blade Bolt(8T)M12*25 P=1.25Meck |
2 |
|
|
15 |
0223-56100 |
Rotery Cover CMP |
1 |
|
|
14 |
0223-51800 |
Washer for Knife Bracket Holder |
1 |
|
|
13 |
0223-51700 |
Knife Bracket |
1 |
|
|
12 |
0223-50200 |
Gear Case Bracket |
1 |
|
|
11 |
89-1750-160002 |
Spring Washer 16 |
1 |
|
|
10 |
89-1750-120002 |
Spring Washer 12 |
2 |
|
|
9 |
89-1750-080002 |
Spring Washer 8 |
10 |
|
|
8 |
89-1711-080002 |
Flat Washer 8 |
10 |
|
|
7 |
89-1671-080042 |
Mini Hexagonal Cap Nut M8 |
6 |
|
|
6 |
89-1253-080162 |
Flange Hexagonal Bolt (8T) M8*16 |
4 |
|
|
5 |
89-1232-100202 |
Mini Hexagonal Bolt (SW) M10*20 |
2 |
|
|
4 |
89-1211-080182 |
Mini Hexagonal Bolt M8*18 |
6 |
|
|
3 |
83-1732-175-00 |
Bag Nut M16 (Rock) |
1 |
|
|
2 |
80-1493-836-00 |
Knife Neck Guard |
1 |
|
|
1 |
80-1030-821-00 |
Blade H40 |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Cutting Parts
& Cover 4/5 20/30
|
||||
|
10 |
0223-51100 |
Horizontal Shaft |
1 |
|
|
9 |
89-5121-255208 |
Oil Seal UE 25.52.8 |
1 |
|
|
8 |
89-3111-062054 |
Bearing 6205 |
1 |
|
|
7 |
89-3111-062044 |
Bearing 6204 |
1 |
|
|
6 |
89-2512-000520 |
Snap Ring
（R52） |
1 |
|
|
5 |
89-2150-050250 |
Key 5*25(round) |
1 |
|
|
4 |
89-1232-080122 |
Mini Hexagonal Bolt (SW) M8*12 |
4 |
|
|
3 |
83-1210-684-00 |
Oil Cap, KRM-A2 |
1 |
|
|
2 |
84-1713-606-00 |
Gear Box Cover |
1 |
|
|
1 |
80-1415-618-00 |
Bevel Gear 20T, Left |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Cutting Parts
& Cover 5/5 21/30 |
||||
|
12 |
89-5230-100000 |
Seal Washer 10 |
1 |
|
|
11 |
89-5121-355508 |
Oil Seal UE 35.55.8 |
1 |
|
|
10 |
89-3111-062054 |
Bearing 6205 |
1 |
|
|
9 |
89-3111-060064 |
Bearing 6006 |
1 |
|
|
8 |
89-2512-000550 |
Snap Ring
（R55） |
1 |
|
|
7 |
89-2511-000200 |
Snap Ring
（S20） |
1 |
|
|
6 |
89-2150-050250 |
Key 5*25(round) |
1 |
|
|
5 |
89-1251-100122 |
Flange Hexagonal Bolt M10*12 |
1 |
|
|
4 |
83-1415-662-00 |
Oil Seal AP 35.55.8 |
1 |
|
|
3 |
80-1415-641-00 |
Shaft |
1 |
|
|
2 |
80-1415-622-00 |
Bevel Gear 20T, Right |
1 |
|
|
1 |
80-1415-601-10 |
Gear Case |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Transmission 1/9 22/30
|
||||
|
17 |
0223-03600 |
Tension Arm Shaft |
1 |
|
|
16 |
0223-03500 |
Side Clutch Arm CMP |
2 |
|
|
15 |
0223-03400 |
Side Clutch Wire Receiver (L) |
1 |
|
|
14 |
0223-03300 |
Side Clutch Wire Receiver (R) |
1 |
|
|
13 |
0223-03200 |
Change Arm CMP |
1 |
|
|
12 |
89-5121-304707 |
Oil Seal UE 30.47.7 |
2 |
|
|
11 |
89-1750-080002 |
Spring Washer 8 |
1 |
|
|
10 |
89-1750-060002 |
Spring Washer 6 |
1 |
|
|
9 |
89-1543-080002 |
Mini Hexagonal Nut (SW) M8 |
2 |
|
|
8 |
89-1253-081453 |
Small Flange Bolt (8T)M8*145 |
2 |
|
|
7 |
89-1253-081203 |
Small Flange Bolt (8T)M8*120 |
1 |
|
|
6 |
89-1111-060252 |
Hexagonal Bolt M6*25 |
1 |
|
|
5 |
83-1484-255-00 |
Rock Nut ZUF M8 |
2 |
|
|
4 |
83-1482-311-00 |
Washer 6.5*22*3.2 |
1 |
|
|
3 |
83-1415-663-00 |
Oil Seal AP 30.47.7 |
2 |
|
|
2 |
80-1415-441-00 |
Dust Cover |
2 |
|
|
1 |
80-1020-270-00 |
Inner Collar |
2 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Transmission 2/9 23/30
|
||||
|
12 |
0223-03100 |
Mission Guard CMP |
1 |
|
|
11 |
89-5221-018000 |
O Ring P18 |
1 |
|
|
10 |
89-1254-101153 |
Flange Hexagonal Bolt M10*1.25*115 |
1 |
|
|
9 |
89-1254-100122 |
Flange Hexagonal Bolt M10*1.25*12 |
1 |
|
|
8 |
89-1253-081453 |
Small Flange Bolt (8T)M8*145 |
1 |
|
|
7 |
89-1253-081403 |
Small Flange Bolt (8T)M8*140 |
4 |
|
|
6 |
89-1253-081203 |
Small Flange Bolt (8T)M8*120 |
1 |
|
|
5 |
89-1253-081153 |
Small Flange Bolt (8T)M8*115 |
1 |
|
|
4 |
83-1493-255-00 |
Washer Based Rock Nut(slender)M10 |
1 |
|
|
3 |
83-1484-255-00 |
Rock Nut ZUF M8 |
7 |
|
|
2 |
83-1020-349-00 |
Packing 10.5*18*1.6 |
1 |
|
|
1 |
80-1032-119-00 |
Oil Cock M22 |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Transmission 3/9 24/30
|
||||
|
14 |
0223-02900 |
Axle BB Case (Left) |
1 |
|
|
13 |
0223-00200 |
Transmission Case(L) |
1 |
|
|
12 |
89-5121-284708 |
Oil Seal UE 28.47.8. |
1 |
|
|
11 |
89-5121-153007 |
Oil Seal UE 15.30.7 |
1 |
|
|
10 |
89-5121-122207 |
Oil Seal UE 12.22.7 |
1 |
|
|
9 |
89-3115-060054 |
Bearing 6005 2RS |
2 |
|
|
8 |
89-2512-000470 |
Snap Ring （R47） |
1 |
|
|
7 |
89-2111-050020 |
Spring Pin 5*20 |
1 |
|
|
6 |
89-2111-030020 |
Spring Pin 3*20 |
1 |
|
|
5 |
83-1415-672-00 |
Black Cap 30 |
1 |
|
|
4 |
83-1415-671-00 |
Black Cap 22 |
1 |
|
|
3 |
83-1415-127-00 |
Seal Bolt(SW) M8x20 |
4 |
|
|
2 |
80-1425-112-00 |
Driving Clutch Folk Shaft |
1 |
|
|
1 |
80-1415-114-00 |
Side Clutch Folk |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Transmission 4/9 25/30
|
||||
|
9 |
0223-02700 |
Axle CMP |
1 |
|
|
8 |
0223-00700 |
1st Shaft Shift Gear 14T |
1 |
|
|
7 |
0223-00400 |
Shift Fork Shaft |
1 |
|
|
6 |
0223-00300 |
Shift Fork |
1 |
|
|
5 |
89-3410-075000 |
Steel Ball 7.5 |
1 |
|
|
4 |
89-3111-062024 |
Bearing 6202 |
4 |
|
|
3 |
89-2120-200202 |
Split Pin 2*20 |
1 |
|
|
2 |
80-1920-147-00 |
Axle Collar |
1 |
|
|
1 |
80-1310-138-00 |
Spring 1.4 |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Transmission 5/9 26/30
|
||||
|
8 |
0223-02400 |
Collar 11L |
1 |
|
|
7 |
0223-00600 |
1st Shaft Gear 20T |
1 |
|
|
6 |
0223-00500 |
1st Shaft |
1 |
|
|
5 |
89-2511-000160 |
Snap Ring
（S16） |
1 |
|
|
4 |
89-2511-000150 |
Snap Ring （S15） |
1 |
|
|
3 |
83-1633-362-10 |
Thrust Washer 15*30*1.2 |
1 |
|
|
2 |
80-1575-162-00 |
Side Clutch Spring |
1 |
|
|
1 |
80-1032-141-00 |
Side Clutch Gear 14T |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Transmission 6/9 27/30
|
||||
|
12 |
0223-02100 |
3rd Shaft Gear 20T CMP |
1 |
|
|
11 |
0223-01300 |
2nd Shaft Gear 28T |
1 |
|
|
10 |
0223-01200 |
Back Gear CMP |
1 |
|
|
9 |
89-2511-000200 |
Snap Ring （S20） |
2 |
|
|
8 |
89-2511-000150 |
Snap Ring （S15） |
1 |
|
|
7 |
83-1830-368-00 |
Thrust Washer 18*26*1.0 |
2 |
|
|
6 |
83-1633-362-10 |
Thrust Washer 15*30*1.2 |
1 |
|
|
5 |
83-1310-371-00 |
Thrust Washer 20*30*1.0 |
1 |
|
|
4 |
80-1575-162-00 |
Side Clutch Spring |
1 |
|
|
3 |
80-1575-142-00 |
Side Clutch Gear 38T |
1 |
|
|
2 |
80-1032-141-00 |
Side Clutch Gear 14T |
1 |
|
|
1 |
80-1032-140-00 |
Side Clutch Shaft |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Transmission 7/9 28/30
|
||||
|
9 |
0223-02500 |
Collar 6L |
2 |
|
|
8 |
0223-02400 |
Collar 11L |
1 |
|
|
7 |
0223-01600 |
3rd Shaft Gear 28T CMP |
1 |
|
|
6 |
0223-01500 |
3rd Shaft Gear 31T |
1 |
|
|
5 |
0223-01400 |
3rd Shaft |
1 |
|
|
4 |
0223-01100 |
2nd Shaft Gear 21T |
1 |
|
|
3 |
0223-00900 |
2nd Shaft Gear 15T |
1 |
|
|
2 |
0223-00800 |
2nd Shaft |
1 |
|
|
1 |
83-1830-368-00 |
Thrust Washer 18*26*1.0 |
2 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Transmission 8/9 29/30
|
||||
|
8 |
0223-02700 |
Axle CMP |
1 |
|
|
7 |
89-5221-009000 |
O Ring P9 |
1 |
|
|
6 |
89-3111-062024 |
Bearing 6202 |
4 |
|
|
5 |
89-2111-050020 |
Spring Pin 5*20 |
1 |
|
|
4 |
89-2111-030020 |
Spring Pin 3*20 |
1 |
|
|
3 |
80-1575-109-00 |
Sub Speed Change Swing Arm |
1 |
|
|
2 |
80-1425-112-00 |
Driving Clutch Folk Shaft |
1 |
|
|
1 |
80-1415-114-00 |
Side Clutch Folk |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
|
Transmission 9/9 30/30
|
||||
|
13 |
0223-02800 |
Axle BB Case (Right) |
1 |
|
|
12 |
0223-00100 |
Transmission Case(R) |
1 |
|
|
11 |
89-5221-018000 |
O Ring P18 |
1 |
|
|
10 |
89-5121-284708 |
Oil Seal UE 28.47.8. |
1 |
|
|
9 |
89-5121-153007 |
Oil Seal UE 15.30.7 |
1 |
|
|
8 |
89-5121-122207 |
Oil Seal UE 12.22.7 |
1 |
|
|
7 |
89-3510-012200 |
DU Bush 12.20 |
1 |
|
|
6 |
89-3115-060054 |
Bearing 6005 2RS |
2 |
|
|
5 |
89-2512-000470 |
Snap Ring （R47） |
1 |
|
|
4 |
83-1415-672-00 |
Black Cap 30 |
1 |
|
|
3 |
83-1415-671-00 |
Black Cap 22 |
1 |
|
|
2 |
83-1415-127-00 |
Seal Bolt(SW) M8x20 |
4 |
|
|
1 |
80-1032-119-00 |
Oil Cock M22 |
1 |
|
|
Ref. |
Parts Number |
Parts Name |
Quantity |
Remarks |
