OREC ISSUED NO. RM94-1
Parts catalogue RABBIT MOWER
(EXPORT MODEL)
RM94
MODEL CODE NO.
RM94 0261-∆∆∆∆∆
|
|
CONTENTS |
|
OREC CO.,LTD.
Update : May 2007
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
1 |
0217-20110 |
Frame CMP |
1 |
|
|
2 |
0215-80100 |
Sub Frame CMP |
1 |
|
|
3 |
89-2191-080502 |
Round Head Pin 8*50 |
2 |
|
|
4 |
89-2131-080002 |
Snap Pin 8 |
2 |
|
|
6 |
89-1236-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
2 |
|
|
7 |
0207-63100 |
Front Cover |
1 |
|
|
8 |
80-1484-904-00 |
Label, Main |
1 |
|
|
9 |
0207-76500 |
Long Knob Bolt M8*20 |
1 |
|
|
10 |
80-1484-356-00 |
Brake Stopper Return Spring |
1 |
|
|
11 |
80-1484-355-00 |
Brake Stopper |
1 |
|
|
12 |
89-1713-100002 |
Flat Washer 10 (large) |
1 |
|
|
13 |
89-1561-100002 |
Mini Hexagonal U Nut M10 |
1 |
|
|
14 |
89-1713-100002 |
Flat Washer 10 (large) |
4 |
|
|
15 |
0207-72700 |
Gas Spring KMF 50-40 |
1 |
|
|
16 |
89-1561-100002 |
Mini Hexagonal U Nut M10 |
2 |
|
|
17 |
89-1713-100002 |
Flat Washer 10 (large) |
4 |
|
|
18 |
89-1232-100202 |
Mini Hexagonal Bolt (SW) M10*20 |
4 |
|
|
19 |
83-1020-355-00 |
Thrust Washer 12*24*1.0 |
2 |
|
|
20 |
80-1484-354-10 |
Brake Rod Roller |
1 |
|
|
21 |
89-3510-012200 |
DU Bush 12.20 |
1 |
|
|
22 |
83-1751-311-00 |
Washer 8*25*2.3 |
1 |
|
|
23 |
89-1543-080002 |
Mini Hexagonal Nut (SW) M8 |
1 |
|
|
24 |
0261-20800 |
Seat Receiver |
1 |
|
|
25 |
80-1481-944-00 |
Seat GTP-4 (Black) |
1 |
|
|
26 |
83-1560-101-00 |
Knob Bolt M8*15 |
2 |
|
|
27 |
89-1750-080002 |
Spring Washer 8 |
2 |
|
|
28 |
89-1713-080002 |
Flat Washer 8 (large) |
2 |
|
|
29 |
0207-20500 |
Step |
1 |
|
|
30 |
0207-20600 |
Step Rubber |
1 |
|
|
31 |
83-1484-369-00 |
Clip (5347) |
15 |
|
|
32 |
0207-20400 |
Seat Bracket |
1 |
|
|
33 |
0223-76100 |
Label, Caution (Large) |
1 |
|
|
34 |
0207-21200 |
Seat Bracket Shaft |
1 |
|
|
35 |
89-1553-060002 |
Bag Hexagonal U Nut M6 |
2 |
|
|
36 |
80-1481-487-00 |
Seat Receive Pin |
1 |
|
|
37 |
89-2131-120002 |
Snap Pin 12 |
2 |
|
|
38 |
0207-76100 |
Trim 15*350 |
2 |
|
|
39 |
0207-76700 |
Knob Bolt (KG-B2) M8*20 |
1 |
|
|
40 |
89-1713-080002 |
Flat Washer 8 (large) |
1 |
|
|
41 |
0207-76900 |
Bonded Washer 8 |
1 |
|
|
42 |
0207-70900 |
Grommet 30-3.2 (KG-G79QB) |
1 |
|
|
43 |
89-1236-080202 |
Mini Hexagonal Bolt (PWSW) M8*20 |
8 |
|
|
44 |
0207-70800 |
Grommet 45-3.5 |
1 |
|
|
45 |
0207-20300 |
Engine Base |
1 |
|
|
46 |
89-1236-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
2 |
|
|
47 |
80-1792-988-00 |
Harness Clip 8 |
2 |
|
|
48 |
89-1671-080042 |
Mini Cap Nut M8 |
2 |
|
|
49 |
0207-61100 |
Fender (L) |
1 |
|
|
50 |
0207-61200 |
Fender (R) |
1 |
|
|
51 |
0207-76600 |
Ditch Rubber 3.2*100 |
1 |
|
|
52 |
89-1390-060162 |
Welded Bolt M6*16 |
1 |
|
|
53 |
0207-72900 |
Seat Switch Spring |
1 |
|
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
54 |
0261-21200 |
Seat Receiving Bolt M8*175*35 |
2 |
|
|
55 |
0261-21100 |
Seat Spring Receiver CMP |
1 |
|
|
56 |
89-1631-080042 |
Flange Mini Hexagonal Nut M8 |
2 |
|
|
57 |
0215-81600 |
Seat Spring 167 |
2 |
|
|
58 |
0207-21300 |
Protection Guard |
1 |
|
|
59 |
83-1490-114-00 |
Mini Hexagonal Bolt (PWSW) M8*20 |
1 |
|
|
60 |
80-1792-988-00 |
Harness Clip 8 |
1 |
|
|
61 |
89-1511-060042 |
Hexagonal Nut M6 |
1 |
|
|
62 |
89-1159-060168 |
Truss Mini Screw M6*16 |
4 |
|
|
63 |
89-1232-080202 |
Mini Hexagonal Bolt (SW) M8*20 |
2 |
|
|
64 |
83-1020-314-00 |
Washer 8*40*2.3 |
2 |
|
|
65 |
0207-76400 |
Washer 9*25*3.2 |
2 |
|
|
68-70 |
0207-71000 |
Fuel Tank Assy |
1 |
|
|
68 |
0207-71100 |
Tank CMP |
1 |
|
|
69 |
0207-71300 |
Filter (with level) |
1 |
|
|
70 |
0207-71200 |
Cap |
1 |
|
|
71 |
0261-61100 |
Tank Holder CMP |
1 |
|
|
72 |
0261-61200 |
Air Intake Guard CMP |
1 |
|
|
73 |
89-1137-060122 |
Hexagonal Bolt (PW) M6*12 |
2 |
|
|
74 |
0244-72800 |
Wind Shield |
1 |
|
|
75 |
89-1159-060168 |
Truss Mini Screw M6*16 |
3 |
|
|
76 |
89-1713-060002 |
Flat Washer 6 (large) |
3 |
|
|
77 |
89-1511-060042 |
Hexagonal Nut M6 |
3 |
|
|
78 |
89-1236-080202 |
Mini Hexagonal Bolt (PWSW) M8*20 |
4 |
|
|
80 |
0207-10510 |
Cutting Height Guide |
1 |
|
|
81 |
89-1232-100202 |
Mini Hexagonal Bolt (SW) M10*20 |
4 |
|
|
82 |
0217-70610 |
Label, Cutting Height Adjusting (13201) |
1 |
|
|
83 |
80-1488-915-00 |
Label, Knife (13114) |
1 |
|
|
84 |
80-1515-339-00 |
Handle Grip 15 |
1 |
|
|
85 |
80-1482-272-00 |
Cutting Height Adjust Lever |
1 |
|
|
86 |
80-1484-262-00 |
Arm Grip (Red) |
1 |
|
|
87 |
0207-13800 |
Knife Clutch Lever |
1 |
|
|
88 |
89-2521-000120 |
E Type Ring 12 |
1 |
|
|
89 |
80-1487-274-00 |
Cutting Height Lever Spring |
1 |
|
|
90 |
0207-76800 |
Washer 16*32*2.3 |
2 |
|
|
91 |
89-2120-300252 |
Split Pin 3*25 |
2 |
|
|
92 |
0207-70310 |
Cutting Clutch Wire |
1 |
|
|
93 |
89-1711-060002 |
Flat Washer 6 |
3 |
|
|
94 |
89-2120-200152 |
Split Pin 2*15 |
3 |
|
|
95 |
0207-78400 |
Spring For Knife Tension Return |
1 |
|
|
96 |
0217-10410 |
Up/Down Adjusting Shaft CMP |
1 |
|
|
97 |
89-1611-080042 |
Mini Hexagonal Nut M8 |
1 |
|
|
98 |
89-1211-080257 |
Mini Hexagonal Bolt M8*25 |
1 |
|
|
99 |
83-1020-312-00 |
Washer 8*30*3.2 |
2 |
|
|
100 |
89-1232-080252 |
Mini Hexagonal Bolt (SW) M8*25 |
2 |
|
|
101 |
0207-77510 |
Knife Brake Wire |
1 |
|
|
102 |
89-2181-060162 |
Flat Head Pin 6*16 |
2 |
|
|
103 |
89-1211-080552 |
Mini Hexagonal Bolt M8*55 |
2 |
|
|
104 |
89-1611-080042 |
Mini Hexagonal Nut M8 |
1 |
|
|
105 |
0207-11710 |
Change Bracket CMP |
1 |
|
|
106 |
89-1236-080202 |
Mini Hexagonal Bolt (PWSW) M8*20 |
3 |
|
|
107 |
83-1565-329-00 |
Washer 13*22*2.3 |
1 |
|
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
108 |
0207-72300 |
Change Brake Adjuster |
1 |
|
|
109 |
0207-72200 |
Change Brake Spring |
1 |
|
|
110 |
0207-11400 |
Change Brake |
1 |
|
|
111 |
89-3510-012200 |
DU Bush 12.20 |
2 |
|
|
114 |
0207-11610 |
Change Beam |
1 |
|
|
115 |
89-1750-060002 |
Spring Washer 6 |
2 |
|
|
116 |
89-1111-060142 |
Hexagonal Bolt M6*14 |
2 |
|
|
117 |
0207-11310 |
Change Boss CMP |
1 |
|
|
118 |
89-3510-016250 |
DU Bush 16.25 |
2 |
|
|
119 |
0207-76800 |
Washer 16*32*2.3 |
1 |
|
|
120 |
0207-12900 |
Change Lever CMP |
1 |
|
|
121 |
89-1213-080302 |
Mini Hexagonal Bolt (8T) M8*30 |
1 |
|
|
122 |
89-1561-080002 |
Mini Hexagonal U Nut M8 |
1 |
|
|
123 |
0221-13200 |
Change Grip |
1 |
|
|
124 |
0207-11810 |
Sub Change Lever CMP |
1 |
|
|
125 |
89-3510-012200 |
DU Bush 12.20 |
1 |
|
|
126 |
0207-77700 |
Push Lever Spring |
1 |
|
|
127 |
80-1321-218-00 |
Stopper Pin Holder |
1 |
|
|
128 |
89-1172-060085 |
Hexagonal Hole Screw M6*8 |
1 |
|
|
129 |
0207-11900 |
Push Lever |
1 |
|
|
130 |
0207-72600 |
Lever Grip 8 (black) |
2 |
|
|
131 |
89-2521-000120 |
E Type Ring 12 |
1 |
|
|
132 |
89-1511-100042 |
Hexagonal Nut M10 |
2 |
|
|
133 |
89-1713-100002 |
Flat Washer 10 (large) |
1 |
|
|
134 |
89-3510-014150 |
DU Bush 14.15 |
1 |
|
|
135 |
0207-12100 |
Throttle Lever |
1 |
|
|
136 |
89-1852-140001 |
Belleville Spring H14 |
2 |
|
|
137 |
0207-12200 |
Throttle Lever Shaft |
1 |
|
|
138 |
0207-12510 |
Change Guide CMP |
1 |
|
|
139 |
0217-70500 |
Label, Change (13167) |
1 |
|
|
140 |
80-1488-924-00 |
Label, Chork (13118) |
1 |
|
|
141 |
0217-70200 |
Label, Throttle (13169) |
1 |
|
|
142 |
0217-70100 |
Label, Differential Lock (13168) |
1 |
|
|
143 |
89-1236-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
8 |
|
|
144 |
89-1631-080042 |
Flange Mini Hexagonal Nut M8 |
5 |
|
|
145 |
89-1750-100002 |
Spring Washer 10 |
1 |
|
|
146 |
0207-12400 |
Differential Lock Lever Shaft |
1 |
|
|
147 |
0207-12300 |
Differential Lock Lever CMP |
1 |
|
|
148 |
83-1210-425-00 |
Lever Grip 10 |
1 |
|
|
149 |
80-1020-263-00 |
Control Lever Shaft Spring |
1 |
|
|
150 |
89-1714-100002 |
Flat Washer 10 |
1 |
|
|
151 |
89-1561-100002 |
Mini Hexagonal U Nut M10 |
1 |
|
|
152 |
0207-70700 |
Differential Lock Wire |
1 |
|
|
153 |
80-1425-551-00 |
Differential Lock Spring |
1 |
|
|
154 |
89-2132-060002 |
Snap Pin 6 (with stopper) |
2 |
|
|
155 |
89-2181-060162 |
Flat Head Pin 6*16 |
2 |
|
|
156 |
0207-70200 |
Throttle Wire (B) |
1 |
|
|
157 |
0207-70500 |
Choke Wire B |
1 |
|
|
158 |
80-1487-962-10 |
Rod End PHS10ECL |
1 |
|
|
159 |
83-1488-195-02 |
Mini Hexagonal Nut M10 (L) |
1 |
|
|
160 |
80-1485-265-00 |
Shift Rod Adjuster |
1 |
|
|
161 |
89-1611-100042 |
Mini Hexagonal Nut M10 |
1 |
|
|
162 |
0207-11500 |
Shift Rod |
1 |
|
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
163 |
89-1611-100042 |
Mini Hexagonal Nut M10 |
1 |
|
|
164 |
80-1487-964-10 |
Rod End PHS10EC |
1 |
|
|
165 |
89-1213-100302 |
Mini Hexagonal Bolt (8T) M10*30 |
1 |
|
|
166 |
89-1631-100042 |
Flange Mini Hexagonal Nut M10 |
1 |
|
|
167 |
89-1213-100352 |
Mini Hexagonal Bolt (8T) M10*35 |
1 |
|
|
168 |
89-1711-100002 |
Flat Washer 10 |
1 |
|
|
169 |
89-1631-100042 |
Flange Mini Hexagonal Nut M10 |
1 |
|
|
170 |
89-2131-100002 |
Snap Pin 10 |
2 |
|
|
171 |
0207-11100 |
Sub Change Rod (front) |
1 |
|
|
172 |
89-1611-080042 |
Mini Hexagonal Nut M8 |
1 |
|
|
173 |
80-1791-597-00 |
Turn Buckle 8*50 |
1 |
|
|
174 |
83-1484-195-00 |
Mini Hexagonal Nut M8 (L) |
1 |
|
|
175 |
0207-11200 |
Sub Change Rod (rear) |
1 |
|
|
179 |
0217-70800 |
Label, Gear Oil 1.0L |
1 |
|
|
180 |
0207-13400 |
Change Return Arm |
1 |
|
|
181 |
0207-79100 |
Spring For Change Return Arm |
1 |
|
|
182 |
0207-79500 |
Square Pipe Cap 38 |
2 |
|
|
187 |
83-1310-902-00 |
OREC Mark |
1 |
|
|
188 |
0215-83200 |
Label, Protection Equipment |
1 |
|
|
189 |
0215-83100 |
Attention Mark for Slope |
1 |
|
|
190 |
Not for sale |
Label, model RM94 |
1 |
|
|
191 |
80-1484-907-00 |
Reflection Seat (Yellow) |
2 |
|
|
192 |
80-1484-903-00 |
Label, Rabbit |
1 |
|
|
193 |
80-1488-928-10 |
Label, Caution for Belt Involving |
1 |
|
|
194 |
0207-73700 |
Label, HST |
1 |
|
|
195 |
80-1010-933-00 |
Label, CE |
1 |
|
|
196 |
Not for sale |
Label, Serial No. |
1 |
|
|
197 |
0217-61100 |
Rear Belt Cover |
1 |
|
|
198 |
80-1020-932-00 |
Label, Noise 100db |
1 |
|
|
199 |
0214-72100 |
Label, Caution for Engine etc |
1 |
|
|
|
||||
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
1-98 |
0207-09930 |
Transmission Assy |
1 |
|
|
1-84 |
0207-09820 |
Gear Case Assy |
1 |
|
|
85-95 109.110 |
0207-09720 |
HST Unit Assy |
1 |
|
|
1 |
0207-00100 |
Transmission Case(L) |
1 |
|
|
2 |
0207-00200 |
Transmission Case(R) |
1 |
|
|
3 |
0207-00300 |
A Axle |
1 |
|
|
4 |
89-3115-060044 |
Bearing 6004 2RS |
2 |
|
|
5 |
89-2150-050160 |
Key 5*16 (round) |
1 |
|
|
6 |
0207-00400 |
20T Spiral Mita Gear(L) |
1 |
|
|
7 |
89-2511-000170 |
Snap Ring (S17) |
1 |
|
|
8 |
89-2151-050200 |
Key 5*20 (half round) |
1 |
|
|
9 |
89-2512-000420 |
Snap Ring (R42) |
1 |
|
|
10 |
89-5121-204208 |
Oil Seal UE 20.42.8 |
1 |
|
|
11 |
0207-40200 |
Transmission Pulley |
1 |
|
|
12 |
83-1482-311-00 |
Washer 6.5*22*3.2 |
1 |
|
|
13 |
89-1750-060002 |
Spring Washer 6 |
1 |
|
|
14 |
89-1113-060202 |
Hexagonal Bolt (8T) M6*20 |
1 |
|
|
15 |
0207-01700 |
Swing Arm CMP |
1 |
|
|
16 |
0207-01600 |
Shift Fork Shaft CMP |
1 |
|
|
17 |
89-3410-080000 |
Steel Ball 8.0 |
1 |
|
|
18 |
80-1310-138-00 |
Spring 1.4 |
1 |
|
|
19 |
0207-01900 |
Shift Spring Holder |
1 |
|
|
20 |
83-1020-148-00 |
Tapping Bolt M6*14 |
2 |
|
|
21 |
89-5121-122207 |
Oil Seal UE 12.22.7 |
2 |
|
|
22 |
0207-02500 |
Sub Change Arm |
1 |
|
|
23 |
89-1543-080002 |
Mini Hexagonal Nut (SW) M8 |
2 |
|
|
24 |
89-3111-060044 |
Bearing 6004 |
4 |
|
|
25 |
0207-00600 |
B Axle |
1 |
|
|
26 |
0207-00500 |
20T Spiral Mita Gear(R) |
1 |
|
|
27 |
0207-00700 |
C Axle |
1 |
|
|
28 |
0207-00910 |
Shift Gear 22-28 |
1 |
|
|
29 |
0207-00800 |
C Axle Collar 9 |
1 |
|
|
30 |
89-3111-062024 |
Bearing 6202 |
2 |
|
|
31 |
83-1020-361-00 |
Thrust Washer 15*24*1.0 |
1 |
|
|
32 |
0207-01210 |
Brake Shaft 40T Gear |
1 |
|
|
33 |
0207-01100 |
Brake Shaft |
1 |
|
|
34 |
0207-01310 |
Brake Shaft 34T Gear |
1 |
|
|
35 |
0207-01500 |
Brake Shaft Collar 8 |
1 |
|
|
36 |
89-5121-153007 |
Oil Seal UE 15.30.7 |
1 |
|
|
37 |
89-2511-000150 |
Snap Ring (S15) |
1 |
|
|
38-41 |
0207-73000 |
Brake Assy |
1 |
|
|
38 |
80-1030-282-00 |
Brake Drum (PA-7) |
1 |
|
|
39 |
80-1030-288-00 |
Brake Cover PK (PA-7) |
1 |
|
|
40 |
80-1030-284-00 |
Brake Shoe(PA-7) (0244-88100) |
1 |
|
|
41 |
0207-73100 |
Brake Cap Assy |
1 |
|
|
42 |
89-1750-060002 |
Spring Washer 6 |
4 |
|
|
43 |
89-1113-060122 |
Hexagonal Bolt (8T) M6*12 |
4 |
|
|
44 |
0207-10300 |
Brake Joint |
1 |
|
|
45 |
89-1714-080002 |
Flat Washer 8 |
1 |
|
|
46 |
89-2120-250202 |
Split Pin 2.5*20 |
1 |
|
|
47 |
89-3111-062034 |
Bearing 6203 |
2 |
|
|
48 |
0207-01400 |
D Axle 37T Gear |
1 |
|
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
49 |
0207-02700 |
D Axle |
1 |
|
|
50 |
80-1830-113-00 |
Differential Lock Fork |
1 |
|
|
51 |
0207-01800 |
Differential Lock Fork Shaft |
1 |
|
|
52 |
89-2111-050020 |
Spring Pin 5*20 |
1 |
|
|
53 |
89-2111-030020 |
Spring Pin 3*20 |
1 |
|
|
54 |
89-2511-000400 |
Snap Ring (S40) |
1 |
|
|
55 |
80-1425-143-00 |
Differential Lock Cone |
1 |
|
|
56 |
80-1751-162-00 |
Differential Lock Spring |
1 |
|
|
57 |
83-1830-382-00 |
Thrust Washer 40*48*1.0 |
1 |
|
|
58 |
0207-02800 |
Axle Gear CMP |
1 |
|
|
59 |
0207-02220 |
Axle(R) CMP |
1 |
|
|
60 |
89-3410-075000 |
Steel Ball 7.5 |
3 |
|
|
61 |
80-1415-150-00 |
Axle Pin |
1 |
|
|
62 |
0207-02120 |
Axle(L) CMP |
1 |
|
|
63 |
80-1481-152-00 |
Differential Lock Gear 11T |
4 |
|
|
64 |
80-1481-155-00 |
Differential Gear Shaft Collar |
4 |
|
|
65 |
80-1481-151-00 |
Differential Lock Plate |
1 |
|
|
66 |
89-3510-028300 |
DU Bush 28.30 |
1 |
|
|
67 |
89-2511-000280 |
Snap Ring (S28) |
1 |
|
|
68 |
89-1750-100002 |
Spring Washer 10 |
6 |
|
|
69 |
89-1613-100042 |
Mini Hexagonal Nut (3 sorts) M10 |
6 |
|
|
70 |
89-5121-284708 |
Oil Seal UE 28.47.8 |
2 |
|
|
71 |
89-3115-060054 |
Bearing 6005 2RS |
4 |
|
|
72 |
0207-02310 |
Axle Case(L) CMP |
1 |
|
|
73 |
89-2512-000470 |
Snap Ring (R47) |
2 |
|
|
74 |
83-1415-663-00 |
Oil Seal AP 30.47.7 |
2 |
|
|
75 |
89-1235-080202 |
Mini Hexagonal Bolt (SW) M8*20 |
12 |
|
|
76 |
0207-02410 |
Axle Case(R) CMP |
1 |
|
|
77 |
80-1488-153-00 |
Differential Lock Arm |
1 |
|
|
78 |
89-1251-080253 |
Flange Mini Hexagonal Bolt M8*25 |
9 |
|
|
79 |
83-1482-143-00 |
Tapping Bolt M8*25 |
3 |
|
|
80 |
0207-06100 |
Air Bleezer |
1 |
|
|
81 |
83-1415-671-00 |
Blind Cover 22 |
2 |
|
|
82 |
83-1020-349-00 |
Copper Packing 10.5*18*1.6 |
1 |
|
|
83 |
89-1252-100122 |
Flange Mini Hexagonal Bolt M10*12 (slender) |
1 |
|
|
84 |
83-1032-689-00 |
Oil Gauge KMS28A |
1 |
|
|
85 |
0207-07110 |
HST Unit |
1 |
|
|
86 |
0207-07700 |
Port Joint |
1 |
|
|
87 |
0228-70200 |
Horse Band 24 |
2 |
|
|
88 |
0228-70100 |
Oil Hose |
1 |
|
|
89 |
0207-08220 |
Oil Tank Setting |
1 |
|
|
90 |
0207-07630 |
Oil Tank |
1 |
|
|
91 |
0207-02610 |
Control Arm CMP |
1 |
|
|
92 |
89-1511-060042 |
Hexagonal Nut M6 |
1 |
|
|
93 |
89-1113-060162 |
Hexagonal Bolt (8T) M6*16 |
1 |
|
|
94 |
89-2151-050160 |
Key 5*16 (half round) |
1 |
|
|
95 |
89-1543-080002 |
Mini Hexagonal Nut (SW) M8 |
1 |
|
|
96 |
89-5222-045000 |
O Ring G45 |
2 |
|
|
97 |
89-1750-080002 |
Spring Washer 8 |
2 |
|
|
98 |
0207-07300 |
Double Spring Bolt |
2 |
|
|
99 |
89-1251-081123 |
Flange Mini Hexagonal Bolt M8*112 |
2 |
|
|
100 |
89-2150-050200 |
Key 5*20 (round) |
1 |
|
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
101 |
0207-07500 |
Fan |
1 |
|
|
102 |
89-1251-080352 |
Flange Mini Hexagonal Bolt M8*35 |
1 |
|
|
103 |
0207-05100 |
Transmission Hunger Stay CMP |
1 |
|
|
104 |
0207-07400 |
Fan Cover Setting CMP |
1 |
|
|
105 |
89-1631-080042 |
Flange Mini Hexagonal Nut M8 |
3 |
|
|
106 |
0207-07200 |
Fan Cover CMP |
1 |
|
|
107 |
0207-03100 |
Mission Guard CMP |
1 |
|
|
108 |
89-1236-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
4 |
|
|
109 |
0207-79800 |
Push Clip |
1 |
|
|
110 |
0207-79900 |
Wire Band 250L |
1 |
|
|
|
||||
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
1 |
0207-30100 |
Front Axle CMP |
1 |
|
|
2 |
89-3510-025350 |
DU Bush 25.35 |
2 |
|
|
3 |
0207-30700 |
Center Pin |
1 |
|
|
4 |
83-1415-975-00 |
Grease Nipple M6 |
1 |
|
|
5 |
89-1713-120002 |
Flat Washer 12 (large) |
1 |
|
|
6 |
89-1750-120002 |
Spring Washer 12 |
1 |
|
|
7 |
89-1551-120002 |
Hexagonal U Nut M12 |
1 |
|
|
8 |
83-1515-975-00 |
Grease Nipple C-Type M6 |
2 |
|
|
9 |
84-1783-791-00 |
Grease Nipple Bolt M14 |
2 |
|
|
10 |
89-1750-140002 |
Spring Washer 14 |
2 |
|
|
11 |
84-1783-729-00 |
Dust Cover |
2 |
|
|
12 |
83-1310-371-00 |
Thrust Washer 20*30*1.0 |
4 |
|
|
13 |
89-3511-020200 |
DU Bush 20.20.31F |
4 |
|
|
14 |
83-1493-255-00 |
Flange Lock Nut M10 (slender) |
4 |
|
|
15 |
80-1493-963-00 |
Link Ball LHSA 10DLE21 |
2 |
|
|
16 |
83-1493-195-00 |
Hexagonal Nut (slender) M10 Left |
2 |
|
|
17 |
0207-13100 |
Tie Rod Adjuster |
2 |
|
|
18 |
89-1512-100042 |
Hexagonal Nut M10 (slender) |
2 |
|
|
19 |
80-1493-962-00 |
Link Ball LHSA 10DE21 |
2 |
|
|
20 |
80-1484-321-30 |
Rack Support |
1 |
|
|
21 |
89-1124-100253 |
Washer Based Bolt M10*25 (slender) |
2 |
|
|
22 |
83-1020-143-00 |
Tapping Bolt M8*18 |
2 |
|
|
23-28 |
80-1484-962-10 |
Steering Gear Box Assy |
1 |
|
|
23 |
80-1484-963-00 |
Steering Gear Box |
1 |
|
|
24 |
80-1484-965-00 |
Steering Horizontal Shaft |
1 |
|
|
25 |
89-3111-062024 |
Bearing 6202 |
1 |
|
|
26 |
80-1484-964-00 |
Steering Vartical Shaft |
1 |
|
|
27 |
89-3114-062024 |
Bearing 6202 ZZ |
1 |
|
|
28 |
89-2512-000350 |
Snap Ring (R35) |
1 |
|
|
29 |
80-1490-967-00 |
Steering Boots |
2 |
|
|
30 |
80-1484-327-20 |
Steering Bracket |
1 |
|
|
31 |
89-1232-080162 |
Mini Hexagonal Bolt (SW) M8*16 |
4 |
|
|
32 |
89-1211-080702 |
Mini Hexagonal Bolt M8*70 |
2 |
|
|
33 |
83-1020-312-00 |
Washer 8*30*3.2 |
2 |
|
|
34 |
89-1213-080202 |
Mini Hexagonal Bolt (8T) M8*20 |
2 |
|
|
35 |
89-1750-080002 |
Spring Washer 8 |
4 |
|
|
36 |
89-1713-080002 |
Flat Washer 8 (large) |
2 |
|
|
37 |
89-1611-080042 |
Mini Hexagonal Nut M8 |
2 |
|
|
38 |
80-1016-461-00 |
Bearing Cover |
1 |
|
|
39 |
89-2150-050200 |
Key 5*20 (round) |
1 |
|
|
40 |
83-1493-149-00 |
Hexagonal Screw M8*10 |
1 |
|
|
41 |
80-1481-324-10 |
Steering Lower Shaft |
1 |
|
|
42 |
0262-10200 |
Steering Upper Shaft |
1 |
|
|
43 |
89-1113-060352 |
Hexagonal Bolt (8T) M6*35 |
1 |
|
|
44 |
89-1553-060002 |
Bag Hexagonal U Nut M6 |
1 |
|
|
45 |
80-1484-325-00 |
Steering Shaft Cover |
1 |
|
|
46 |
83-1020-363-00 |
Thrust Washer 16*24*1.0 |
1 |
|
|
47 |
0262-70400 |
Steering Wheel |
1 |
|
|
48 |
0262-70500 |
Steering Cap |
1 |
|
|
49 |
89-1713-100002 |
Flat Washer 10 (large) |
1 |
|
|
50 |
89-1561-100002 |
Mini Hexagonal U Nut M10 |
1 |
|
|
51 |
80-1484-914-00 |
Label, Handle (25330) |
1 |
|
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
52 |
0262-70300 |
Sub Handle Assy |
1 |
|
|
53 |
0207-30310 |
King Pin (R) CMP |
1 |
|
|
54 |
0207-30210 |
King Pin (L) CMP |
1 |
|
|
55 |
0207-30600 |
Front Wheel Rubber Cover |
2 |
|
|
56 |
0207-30800 |
Front Wheel Rubber Cover (IN) |
2 |
|
|
57 |
0207-30900 |
Front Wheel Rubber Cover Support |
2 |
|
|
58 |
0207-31100 |
King Pin Collar |
2 |
|
|
59 |
89-1631-080042 |
Flange Mini Hexagonal Nut M8 |
8 |
|
|
60 |
0207-30410 |
Front Wheel Boss CMP |
2 |
|
|
61 |
89-3115-060044 |
Bearing 6004 2RS |
4 |
|
|
62 |
80-1260-412-00 |
Front Wheel Tire (R) Assy (3.50-7) |
1 |
|
|
63 |
80-1260-411-00 |
Front Wheel Tire (L) Assy (3.50-7) |
1 |
|
|
64 |
0207-30500 |
Front Wheel Dust Cover |
2 |
|
|
65 |
89-1750-140002 |
Spring Washer 14 |
2 |
|
|
66 |
89-1668-140042 |
Mini Low Fluted Nut (2 sorts) M14 |
2 |
|
|
67 |
89-2120-250252 |
Split Pin 2.5*25 |
2 |
|
|
68 |
89-1232-100202 |
Mini Hexagonal Bolt (SW) M10*20 |
8 |
|
|
69 |
80-1751-412-00 |
Tire (R) Assy (16*7.00-8) |
1 |
|
|
70 |
89-1750-100002 |
Spring Washer 10 |
8 |
|
|
71 |
89-1213-100252 |
Mini Hexagonal Bolt (8T) M10*25 |
8 |
|
|
72 |
80-1751-411-00 |
Tire (L) Assy (16*7.00-8) |
1 |
|
|
73 |
83-1630-335-00 |
Washer 16*40*4.5 |
2 |
|
|
74 |
89-1750-160002 |
Spring Washer 16 |
2 |
|
|
75 |
89-1658-160042 |
Low Fluted Nut (2 sorts) M16 |
2 |
|
|
76 |
89-2120-350352 |
Split Pin 3.5*35 |
2 |
|
|
77 |
0207-31200 |
Rear Wheel Boss |
2 |
|
|
78 |
0207-77800 |
Wheel Boss Dust Seal |
2 |
|
|
79 |
89-2150-070500 |
Key 7*50 (round) |
2 |
|
|
80 |
80-1485-513-00 |
Engine Collar 26 |
1 |
|
|
81 |
0207-40110 |
Engine Pulley |
1 |
|
|
82 |
89-6123-003203 |
V Belt LB-32 (SG1000) |
1 |
|
|
83 |
89-6123-007503 |
V Belt SB-75 (SG1000) |
1 |
|
|
84 |
0207-41310 |
Knife Belt Holder (Engine) CMP |
1 |
|
|
85 |
89-1713-100002 |
Flat Washer 10 (large) |
2 |
|
|
86 |
89-1232-100202 |
Mini Hexagonal Bolt (SW) M10*20 |
2 |
|
|
87 |
83-1437-205-00 |
Key 1/4 inch *40 |
1 |
|
|
88 |
80-1487-516-00 |
Washer 11*40*6 |
1 |
|
|
89 |
83-1493-300-00 |
Spring Washer 7/16 |
1 |
|
|
90 |
83-1482-115-00 |
Hexagonal Bolt(8T) UNF7/16-20*45 |
1 |
|
|
91 |
0207-60700 |
Upper Flapper |
1 |
|
|
92 |
0207-60800 |
Upper Flapper Holder |
1 |
|
|
93 |
89-1137-060152 |
Hexagonal Bolt (PW) M6*15 |
10 |
|
|
94 |
0207-60900 |
Upper Flapper Holder (R) |
1 |
|
|
95 |
83-1575-189-00 |
Flange Cap Nut M6 |
2 |
|
|
96 |
89-1137-060172 |
Hexagonal Bolt (PW) M6*17 |
1 |
|
|
97 |
89-1713-060002 |
Flat Washer 6 (large) |
1 |
|
|
98 |
0207-60600 |
Front Upper Guard |
1 |
|
|
99 |
0228-60500 |
Front Flapper |
1 |
|
|
100 |
0217-63400 |
Foot Guard |
1 |
|
|
101 |
89-1713-100002 |
Flat Washer 10 (large) |
2 |
|
|
102 |
89-1543-100002 |
Mini Hexagonal Nut (SW) M10 |
2 |
|
|
103 |
80-1781-943-00 |
Pedal Rubber |
1 |
|
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
104 |
0207-10100 |
Brake Pedal |
1 |
|
|
105 |
89-3510-016250 |
DU Bush 16.25 |
2 |
|
|
106 |
89-2521-000150 |
E Type Ring 15 |
1 |
|
|
107 |
0207-10200 |
Brake Rod |
1 |
|
|
108 |
89-1213-100352 |
Mini Hexagonal Bolt (8T) M10*35 |
2 |
|
|
109 |
89-1611-100042 |
Mini Hexagonal Nut M10 |
2 |
|
|
110 |
0207-10300 |
Brake Joint |
1 |
|
|
111 |
89-1711-080002 |
Flat Washer 8 |
3 |
|
|
112 |
89-2120-200152 |
Split Pin 2*15 |
1 |
|
|
113 |
0207-75400 |
Brake Spring 30 |
1 |
|
|
114 |
89-1611-080042 |
Mini Hexagonal Nut M8 |
1 |
|
|
115 |
83-1020-363-00 |
Thrust Washer 16*24*1.0 |
2 |
|
|
116 |
80-1483-568-00 |
Knife Tension Return Spring |
1 |
|
|
117-128 |
0207-41000 |
Knife Tension Arm Assy |
1 |
|
|
117 |
89-3510-016250 |
DU Bush 16.25 |
2 |
|
|
118 |
0207-41210 |
Knife Tension Arm |
1 |
|
|
119 |
89-2511-000160 |
Snap Ring (S16) |
1 |
|
|
120 |
89-1611-100042 |
Mini Hexagonal Nut M10 |
1 |
|
|
121 |
89-1750-100002 |
Spring Washer 10 |
1 |
|
|
122 |
89-1713-100002 |
Flat Washer 10 (large) |
1 |
|
|
123 |
83-1482-763-00 |
Tension Pulley Shaft |
1 |
|
|
124 |
80-1482-549-00 |
Rubber Cover 58 |
2 |
|
|
125 |
83-1483-782-00 |
Knife Tension Pulley |
1 |
|
|
126 |
89-3114-062024 |
Bearing 6202 ZZ |
2 |
|
|
127 |
89-2512-000350 |
Snap Ring (R35) |
1 |
|
|
128 |
89-2511-000150 |
Snap Ring (S15) |
1 |
|
|
129 |
83-1415-975-00 |
Grease Nipple M6 |
1 |
|
|
130 |
89-1543-080002 |
Mini Hexagonal Nut (SW) M8 |
4 |
|
|
131 |
89-1213-080402 |
Mini Hexagonal Bolt (8T) M8*40 |
4 |
|
|
132 |
83-1020-363-00 |
Thrust Washer 16*24*1.0 |
2 |
|
|
133 |
89-3510-016150 |
DU Bush 16.15 |
2 |
|
|
134 |
0207-42100 |
Drive Tension Arm CMP |
1 |
|
|
135 |
89-2511-000160 |
Snap Ring (S16) |
1 |
|
|
136 |
89-2512-000400 |
Snap Ring (R40) |
1 |
|
|
137 |
89-3117-062034 |
Bearing 6203 2RD |
1 |
|
|
138 |
83-1032-765-00 |
Tension Pulley |
1 |
|
|
139 |
89-2511-000170 |
Snap Ring (S17) |
1 |
|
|
140 |
0207-72500 |
Drive Tension Spring |
1 |
|
|
141 |
89-1211-100252 |
Mini Hexagonal Bolt M10*25 |
1 |
|
|
142 |
89-1611-100042 |
Mini Hexagonal Nut M10 |
1 |
|
|
143 |
0207-41100 |
Drive Tension Spring Arm |
1 |
|
|
144 |
89-1611-080042 |
Mini Hexagonal Nut M8 |
1 |
|
|
145 |
89-1211-080352 |
Mini Hexagonal Bolt M8*35 |
1 |
|
|
146 |
89-1213-100357 |
Mini Hexagonal Bolt (8T) M10*35 |
2 |
|
|
147 |
80-1493-354-00 |
Rod Return Spring |
1 |
|
|
149 |
0215-81500 |
Label Grease |
4 |
|
|
150 |
83-1490-198-00 |
Hexagonal U Nut M8 (Lock) |
1 |
|
|
|
||||
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
1 |
0207-75110 |
Wire Harness B |
1 |
|
|
2 |
0207-77100 |
Battery Plus Cord 230 |
1 |
|
|
3 |
0207-77200 |
Battery Minus Cord 230 |
1 |
|
|
4 |
89-1236-080202 |
Mini Hexagonal Bolt (PWSW) M8*20 |
2 |
|
|
5 |
0207-74300 |
Head Lamp |
1 |
|
|
6 |
0207-75300 |
Tape |
1 |
|
|
7 |
0207-21100 |
Light Setting Collar |
1 |
|
|
8 |
80-1484-337-00 |
Lighting Switch (B15930) |
1 |
|
|
9 |
89-1211-080352 |
Mini Hexagonal Bolt M8*35 |
1 |
|
|
10 |
89-1631-080042 |
Flange Mini Hexagonal Nut M8 |
2 |
|
|
11 |
0207-20800 |
Light Bracket |
1 |
|
|
12 |
89-1211-080162 |
Mini Hexagonal Bolt M8*16 |
2 |
|
|
13 |
89-1750-080002 |
Spring Washer 8 |
2 |
|
|
14 |
89-1671-080042 |
Mini Cap Nut M8 |
2 |
|
|
15 |
89-1111-060142 |
Hexagonal Bolt M6*14 |
3 |
|
|
16 |
89-1750-060002 |
Spring Washer 6 |
6 |
|
|
17 |
89-1511-060042 |
Hexagonal Nut M6 |
3 |
|
|
18 |
80-1483-978-00 |
Magnetic Switch (MS2-401) |
1 |
|
|
19 |
0207-79700 |
Key Switch |
1 |
|
|
20 |
80-1488-912-00 |
Label, Key (13121) |
1 |
|
|
21 |
80-1482-332-00 |
Key Switch Bracket |
1 |
|
|
22 |
89-1159-060168 |
Truss Mini Screw M6*16 |
4 |
|
|
23 |
89-1631-060042 |
Flange Hexagonal Nut M6 |
4 |
|
|
24 |
0207-72800 |
Switch Lock Nut |
3 |
|
|
25 |
0207-74400 |
Safety Switch K17850 |
3 |
|
|
26 |
80-1488-921-00 |
Label Pedal Stopper (13113) |
1 |
|
|
27 |
80-1490-383-40 |
Battery Carrier |
1 |
|
|
28 |
80-1482-971-00 |
Cushion Rubber (Battery) |
1 |
|
|
29 |
80-1792-976-00 |
Battery (32A-19L) |
1 |
|
|
30 |
Battery Parts |
Flange Bolt M6*20 |
2 |
|
|
31 |
Battery Parts |
Hexagonal Nut M6 |
2 |
|
|
32 |
89-1111-060252 |
Hexagonal Bolt M6*25 |
1 |
|
|
33 |
89-1812-060002 |
Toothed washer (inside) 6 |
2 |
|
|
34 |
89-1713-060002 |
Flat Washer 6 (large) |
3 |
|
|
35 |
80-1792-988-00 |
Harness Clip 8 |
2 |
|
|
36 |
89-1571-060042 |
Cap Nut M6 |
1 |
|
|
37 |
0207-10610 |
Cutting Height Switch Bracket |
1 |
|
|
38 |
85-1484-941-00 |
Hour Meter |
1 |
|
|
39 |
85-1484-943-10 |
Hour Meter Bracket |
1 |
|
|
40 |
85-1484-942-00 |
Wire Harness for Hour Meter |
1 |
|
|
41 |
0217-40500 |
Muffler Fixing Plate CMP |
1 |
|
|
42 |
89-1211-101002 |
Mini Hexagonal Bolt M10*100 |
1 |
|
|
43 |
89-1713-100002 |
Flat Washer 10 (large) |
1 |
|
|
44 |
0207-41400 |
Muffler Fixing Pipe (73L) |
1 |
|
|
45 |
89-1543-100002 |
Mini Hexagonal Nut (SW) M10 |
1 |
|
|
46 |
0207-41700 |
Exhaust Cover B (L) |
1 |
|
|
47 |
0207-41600 |
Exhaust Cover B (R) |
1 |
|
|
48 |
89-1236-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
2 |
|
|
49 |
0207-41500 |
Exhause Adapter B |
1 |
|
|
50 |
0207-40300 |
Oil Drain B |
1 |
|
|
51 |
0207-74900 |
Copper Packing 12.5*19*1.0 |
1 |
|
|
52 |
89-1251-120152 |
Flange Mini Hexagonal Bolt M12*15 |
1 |
|
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
53 |
0207-79600 |
Fuel Cock |
1 |
|
|
54 |
89-1714-120002 |
Flat Washer 12 |
1 |
|
|
55 |
89-1514-120042 |
Hexagonal Nut (3 sorts) M12 (slender) |
1 |
|
|
56 |
80-1487-487-00 |
Hose Clip |
4 |
|
|
57 |
0207-71600 |
Fuel Hose |
1 |
|
|
58 |
0207-71700 |
Fuel Hose B |
1 |
|
|
59 |
0207-79300 |
Pilot Lamp |
1 |
|
|
60 |
0207-79200 |
Fuse Box Bracket |
1 |
|
|
61 |
89-1137-060122 |
Hexagonal Bolt (PW) M6*12 |
2 |
|
|
|
||||
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
1 |
80-1481-709-10 |
Link Bolt |
6 |
|
|
2 |
89-1711-120002 |
Flat Washer 12 |
8 |
|
|
3 |
89-1750-120002 |
Spring Washer 12 |
8 |
|
|
4 |
89-1551-120002 |
Hexagonal U Nut M12 |
8 |
|
|
5 |
0207-51600 |
Link Bolt |
2 |
|
|
7 |
0207-51500 |
Link Collar |
2 |
|
|
8 |
0207-51100 |
Link Arm (Front) |
2 |
|
|
9 |
0207-51200 |
Link Arm (L) |
1 |
|
|
10 |
0207-51300 |
Link Arm (R) |
1 |
|
|
11 |
0217-10810 |
Connecting Plate(L) |
1 |
|
|
12 |
0217-10910 |
Connecting Plate(R) |
1 |
|
|
13 |
83-1751-311-00 |
Washer 8*25*2.3 |
4 |
|
|
14 |
89-1232-080252 |
Mini Hexagonal Bolt (SW) M8*25 |
2 |
|
|
15 |
0207-76200 |
Spring |
2 |
|
|
16 |
89-1232-080162 |
Mini Hexagonal Bolt (SW) M8*16 |
2 |
|
|
17 |
80-1484-501-20 |
Knife Belt Cover |
1 |
|
|
18 |
89-1236-080162 |
Mini Hexagonal Bolt (PWSW) M8*16 |
3 |
|
|
19 |
89-1213-120302 |
Mini Hexagonal Bolt (8T) M12*30 |
1 |
|
|
20 |
89-1750-120002 |
Spring Washer 12 |
1 |
|
|
21 |
83-1483-328-00 |
Washer 12*36*4.5 |
1 |
|
|
22 |
0207-50400 |
Knife Pulley CMP |
1 |
|
|
23 |
89-5121-356210 |
Oil Seal UE 35.62.10 |
1 |
|
|
24 |
89-2512-000620 |
Snap Ring (R62) |
2 |
|
|
25 |
89-3115-060074 |
Bearing 6007 2RS |
2 |
|
|
26 |
80-1493-641-00 |
Vertical Shaft |
1 |
|
|
27 |
80-1493-824-00 |
Dust Plate |
1 |
|
|
28 |
89-5121-406212 |
Oil Seal UE 40.62.12 |
1 |
|
|
29 |
80-1493-833-00 |
Knife Bracket |
1 |
|
|
30 |
80-1493-836-00 |
Knife Neck Guard |
1 |
|
|
31 |
0217-50500 |
Knife Stay |
1 |
|
|
32 |
80-1483-821-00 |
Knife |
2 |
|
|
33 |
80-1483-818-00 |
Knife Collar |
2 |
|
|
34.35,37 |
0244-78200 |
Knife Setting Bolt Set M14 |
|
|
|
34 |
0207-50200 |
Knife Setting Bolt M14*34 |
2 |
|
|
35 |
0244-51800 |
Nut Guard 14 |
2 |
|
|
37 |
0244-74600 |
Hard Lock Nut M14 |
2 |
|
|
40 |
89-1750-200002 |
Spring Washer 20 |
1 |
|
|
41 |
83-1483-175-00 |
Bag Nut M20 (Lock) |
1 |
|
|
42 |
83-1483-129-00 |
Mini Hexagonal Bolt (8T) M12*30 |
2 |
|
|
43 |
89-1750-120002 |
Spring Washer 12 |
2 |
|
|
44 |
0207-52120 |
Knife Brake Bracket CMP (NEW) |
1 |
|
|
45 |
80-1482-373-00 |
Brake Return Spring |
1 |
|
|
46 |
83-1565-329-00 |
Washer 13*22*2.3 |
4 |
|
|
47 |
80-1482-371-30 |
Knife Brake (6t) |
1 |
|
|
48 |
89-3510-012200 |
DU Bush 12.20 |
2 |
|
|
49 |
89-2521-000100 |
E Type Ring 10 |
2 |
|
|
50 |
83-1754-329-00 |
Washer 13*22*1.0 |
1 |
|
|
51 |
89-1236-080202 |
Mini Hexagonal Bolt (PWSW) M8*20 |
2 |
|
|
52 |
80-1484-617-00 |
Knife Pulley Belt Holder |
2 |
|
|
53 |
89-1236-080202 |
Mini Hexagonal Bolt (PWSW) M8*20 |
2 |
|
|
54 |
0217-51400 |
Right Cover Up/Down Arm |
1 |
|
|
55 |
89-1213-080202 |
Mini Hexagonal Bolt (8T) M8*20 |
1 |
|
|
Ref. |
Parts No. |
Parts Name |
Quantity |
Remarks |
|
RM94 |
||||
|
B&S 18HP |
||||
|
56 |
89-1561-080002 |
Mini Hexagonal U Nut M8 |
1 |
|
|
57 |
80-1488-747-00 |
Bolt for Right Cover Up/Down Arm |
1 |
|
|
58 |
89-1750-080002 |
Spring Washer 8 |
1 |
|
|
59 |
0207-60100 |
Right Cover Joint (front) |
2 |
|
|
60 |
89-1235-080302 |
Mini Hexagonal Bolt (SW) M8*30 |
2 |
|
|
61 |
0207-60220 |
Right Cover CMP |
1 |
|
|
62 |
80-1488-928-10 |
Label, Caution for Belt Involving |
2 |
|
|
63 |
80-1488-926-10 |
Label, Caution for Knife |
2 |
|
|
64 |
0217-63200 |
Right Front Cover |
1 |
|
|
65 |
0207-61400 |
Right Cover Flapper |
1 |
|
|
66 |
0207-61500 |
Right Cover Flapper Holder |
1 |
|
|
67 |
89-1137-060172 |
Hexagonal Bolt (PW) M6*17 |
2 |
|
|
68 |
83-1575-189-00 |
Flange Cap Nut M6 |
2 |
|
|
69 |
0207-50120 |
Safety Cover |
1 |
|
|
70 |
0217-60300 |
Left Cover CMP |
1 |
|
|
71 |
0217-63300 |
Left Front Cover |
1 |
|
|
72 |
89-1211-080162 |
Mini Hexagonal Bolt M8*16 |
6 |
|
|
73 |
89-1714-080002 |
Flat Washer 8 |
6 |
|
|
74 |
89-1750-080002 |
Spring Washer 8 |
6 |
|
|
75 |
89-1671-080042 |
Mini Cap Nut M8 |
6 |
|
|
76 |
0217-60500 |
Rear Guard |
1 |
|
|
77 |
0207-61700 |
Rear Guard Flapper |
1 |
|
|
78 |
0207-61800 |
Rear Guard Flapper Holder |
1 |
|
|
79 |
89-1137-060152 |
Hexagonal Bolt (PW) M6*15 |
5 |
|
|
80 |
89-1713-060002 |
Flat Washer 6 (large) |
17 |
|
|
81 |
83-1575-189-00 |
Flange Cap Nut M6 |
17 |
|
|
82 |
89-1137-060172 |
Hexagonal Bolt (PW) M6*17 |
3 |
|
|
83 |
0207-61310 |
Rear Side Flapper |
2 |
|
|
84 |
89-1137-060122 |
Hexagonal Bolt (PW) M6*12 |
5 |
|
|
85 |
89-1137-060152 |
Hexagonal Bolt (PW) M6*15 |
5 |
|
|
86 |
89-1137-060202 |
Hexagonal Bolt (PW) M6*20 |
2 |
|
|
87 |
0217-71100 |
Spring for Right Cover |
2 |
|
|
88 |
0215-81900 |
Label, Oiling |
6 |
|
|
89 |
89-1611-080042 |
Mini Hexagonal Nut M8 |
2 |
|
|
|
||||
